IP41 P1.923mm Commercial Advertising HD LED Display MBI5153 600CD/㎡

Price Negotiable

Price: Negotiable

MOQ: 1Sq.m

Delivery Time: 15 working days

Brand: Vegoo

Product Description

1R1G1B / SMD1515 P1.923 Indoor Full color LED Display HD LED Display

P1.923 Indoor Full color LED Display Specification

Product Name				Specification
Pixel Pitch				1.923mm
Pixel Configuration				1R1G1B/SMD1515 Black lamp
Density				270,410 pixel/m2
Moduel Size(L×W)mm				200mm×150mm
Cabinet Size(L×W×H)mm				400mm×300mm×65mm
Module Resolution				104×78
Cabinet Resolution				208×156
Driving Method				1/26 Scan
Driving IC				MBI5153
Brightness				600CD/㎡
Contrast				1000:1
Brightness Adjustment				Auto and Manual
Power Consumption				Max Power:＜1000W
				Average power: ＜450W
Module Weight				0.15kg
Color Temperature				9500K—11500K
Horizontal Viewing Angle				140º
Vertical Viewing Angle				140º
Signal Processing				10 or 14bit
Grey Processing				1024×1024×1024 16834×16834×16834
Control Distance				cable100m,Multimode500m,Single mode 2km
Frame Frequency				65 Hz
Refresh Rate				>3840Hz
Control Mode				Synchronous/Asynchronous
The Opposite Calibration Curve				With Eight Optional Gamma Calibration Curve
				Users can choose the recommended curve or adjust it based on actual situation
MTBF				>50000 hours
Life Span				100,000 Hours
Operating Temperature				Working : -20 - 65 ℃
				Storage : -40 - 85 ℃
Environment Temperature				-30℃ to 60℃; humidity Rh10% to 95%
Remote Control				Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)
Self-checking Technique				Self-inspection, communication test, power test, temperature monitoring (Be customized)
Operating System Platform				WindowsNT,Windows2000,WindowsXP,Windows7
Power Supply				AC 85-264V
Protection Level				IP 41
