Reinforced Food Grade Spring Hose, Spiral Static Dissipative PVC Steel Wire Hose
Price:
＄0.5-＄5
MOQ:
1000m
Delivery Time:
15-30work days
Brand:
ET
Product Description
Reinforced Food Grade Spring Hose, Spiral Static Dissipative PVC Steel Wire Hose
Temperature range: -5°C - +65°C
Characteristic: The hose is light and transparent, with small bending radius, good adaptability to adverse weather conditions and low pressure. It is an ideal choice for industrial, agricultural and civil drawing transportation of water, powder and oil.
| Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | weight | coil | |||
| inch | mm | mm | bar | psi | bar | psi | g/m | m |
| 1/4 | 6 | 11 | 8 | 120 | 24 | 360 | 115 | 100 |
| 5/16 | 8 | 14 | 8 | 120 | 24 | 360 | 150 | 100 |
| 3/8 | 10 | 16 | 8 | 120 | 24 | 360 | 200 | 100 |
| 1/2 | 12 | 18 | 8 | 120 | 24 | 360 | 220 | 100 |
| 5/8 | 15 | 22 | 6 | 90 | 18 | 270 | 300 | 50 |
| 3/4 | 19 | 26 | 6 | 90 | 18 | 270 | 360 | 50 |
| 1 | 25 | 33 | 5 | 75 | 16 | 240 | 540 | 50 |
| 1-1/4 | 32 | 40 | 5 | 75 | 16 | 240 | 700 | 50 |
| 1-1/2 | 38 | 48 | 5 | 75 | 15 | 225 | 1000 | 50 |
| 2 | 50 | 62 | 5 | 75 | 15 | 225 | 1600 | 50 |
| 2-1/2 | 64 | 78 | 4 | 60 | 12 | 180 | 2500 | 30 |
| 3 | 76 | 90 | 4 | 60 | 12 | 180 | 3000 | 30 |
| 3-1/2 | 90 | 106 | 4 | 60 | 12 | 180 | 4000 | 20 |
| 4 | 102 | 118 | 4 | 60 | 12 | 180 | 4500 | 20 |
| 5 | 127 | 143 | 3 | 45 | 9 | 135 | 6000 | 10 |
| 6 | 152 | 168 | 2 | 30 | 6 | 90 | 7000 | 10 |
| 8 | 202 | 224 | 2 | 30 | 6 | 90 | 12000 | 10 |
| 10 | 254 | 276 | 2 | 30 | 6 | 90 | 20000 | 10 |
