Eccentric Reducer Types Pipe Reducer Stainless Steel Tube Fittings , Seamless SS Pipe Fittings
Industrial pipe fittings eccentric reducer types pipe reducer industrial level fittings price
Description:
Stainless steel pipe is a kind of pipe fittings, stainless steel material is it made so called stainless steel pipe fittings, it includes: stainless steel elbow, stainless steel tee, cross stainless steel, stainless steel reducer, stainless steel pipe cap, etc., according to join method can be divided into the socket type stainless steel pipe fittings, flanges threaded stainless steel pipe fittings, stainless steel pipes and welded stainless steel pipe fittings four classes.Stainless steel elbow is used for where the pipe turns;The flange is used for the part that connects the pipe to the pipe, connected to the pipe end, and the stainless steel tee pipe is used for the place where the three pipes come together.The stainless steel four-way pipe is used for the place where four pipes are collected;Stainless steel reducer is used where two pipes of different sizes are connected.Main stainless steel materials :304, 304L, 316, 316L
Pipe fittings is widely used in kinds of industry and building areas all over the world.It can be used for shipbuliding,petroleum,chemical,gas,power,construction,etc.
Futures:
Main material: 304 (0Crr18Ni9)
Product characteristics: Good corrosion resistance, heat resistance, low temperature strength and mechanical properties. Good hot workability such as stamping and bending.
Product use: household appliances, auto parts, medical equipment, building materials, chemicals, food industry, agriculture, marine, atomic energy equipment.
Product specifications: outer diameter: 6-762mm, wall thickness is clean coal, maximum length: 18000mm, special specifications can be negotiated.
The stainless steel fluid tube is safe, reliable, hygienic and environmentally friendly, economical, and the pipe wall is thin, and the connection method is simple and convenient.
Specification:
| Porduct Name | Pipe reducer |
| Size | 1/2"-24" seamless,26“-110”welded |
| Standard | ANSI B16.9,MSS SP 43, DIN2616, EN10253-4, GOST17378, JIS B2313, MSS SP 75, etc. |
| Wall thickness | Sch5S, Sch10S, Sch10, Sch40S,STD, XS, XXS, Sch20,Sch30,Sch40, Sch60, Sch80, Sch160, XXS and etc. |
| Type | Concentric and eccentric |
| End | bevel end/BE/buttweld |
| Surface | pickled,sand rolling,brighten,matt polished,mirror polished |
| Material | Stainless steel: A403 WP304/304L, A403 WP316/316L, A403 WP321, A403 WP310S, A403 WP347H, A403 WP316Ti, A403 WP317, 904L,1.4301,1.4307,1.4401,1.4571,1.4541, 254Mo and etc. |
| Duplex stainless steel: UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462,1.4410,1.4501 and etc. | |
| Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H, C22, C-276, Monel400, Alloy20 etc. | |
| Application | Petrochemical industy;avation and aerospace industry;pharmaceutical industry;gas exhaust; power plant;ship buliding;water treament,etc. |
| Advantages | Ready stock,faster delivery time;available in all sizes,austomized;high quality |
If you want size of 10" up to 24", can be seamless or welded
1/2" up to 8" size, we suggest you choose seamless type
1) Produce theShort radius heavy wall carbon steel elbows pipe fitting by advanced production equipment .
2)Third Party Inspection is accepted as customer's request.
3)Short radius heavy wall carbon steel elbows pipe fitting is popular to allover the world.
4)Short radius heavy wall carbon steel elbows pipe fitting can withstand pressure as customer's request.
