Maintenance

There are two fi lters in the unit. The evaporator fi lter is located at the front of the unit. The condenser fi lter is located at the side of the unit.

1. loosen up 2 bolts on the front fi lter guard.

2. Slide fi lter up and use a vacuum cleaner to remove the dust from the fi lter.

3. Replace the clean fi lter and close the fi lter guard.

4. To clean the condenser fi lter, lift up on the side fi lter from the middle bar slightly and then angle the fi lter outwards from the bottom and remove.

5. To replace the condenser fi lter, place the top of the fi lter in the guide and slide the fi lter up until the bottom of the fi lter clears the frame. Then push the bottom of fi lter into the guide and let fi lter gently fall inside the guide. NOTE: For effective cooling clean the fi lter at least every 2 weeks.
