420mm Swing Over Flat Bed CNC Lathe Machine , 2800rpm Spindle CNC Metal Lathe
420mm Swing Over Table Flant Type CNC Lathe Machine CKI6136 2800rpm Spindle
Quick details:
1. It is made from the whole cast-iron, which is heavy enough with good rigidity and
stability.
2. Variable speed regulation, with lower noise and high- standard machining accuracy, is an environmental- protective machine.
3. The spindle is the high- rotate speed and sophisticated bearing with smooth surface.
4. The extra size diameter of the spindle bore is φ70mm while the diameter of chuck is φ200mm.
Product advantage
1. Machine body guide way are quenched for better resistance of abrasion ,and increased stability and accuracy
2. 6136,6140machine employ intergrated body structure,and extra wide guide way with better vibration resistance
3. spindle ,saddle adopt special structure and technology ,which increase precision, stability and accuracy
4. Models above 6150 adopt gear box transmission design ,and are equipped with inverter spindle motor which can enable strong cutting force with 3-level gear speed, and change rotation speed by controller system at each speed level
5. optional controller system, Gsk control system, KND control system ,and fanuc control system
Specification Of Flat Bed CNC Lathe Machine CKI6136
| Item | Unit | CKI6136 |
| Max swing over table | mm | 420 |
| Max swing diameter over carriage | mm | 230 |
| Spindle head | A2-6 | |
| Max processing length | mm | 750 |
| X axis Travel | mm | 235 |
| Z axis Travel | mm | 750 |
| Spindle through hole diameter | mm | 58 |
| Spindle motor | kw | 5.5 |
| Spindle rotation speed | rpm | 3200 |
| Servo motor connection type | Direct connection | |
| X axis rapid feed | m/min | 4 |
| Z axis rapid feed | m/min | 6 |
| Tool width*height | mm | 20*20 |
| Turret center height | mm | ≤105 |
| Tailstock Shaft diameter*travel | mm | φ65*120 |
| Tailstock taper | MT4 | |
| Positioning accuracy | mm | 0.01 |
| Power | kw/h | 9 |
| Dimension | mm | 2385*1200*1800 |
| Net weight | kg | 1600 |
Standard Accessories:
GSK 980TDi Controller system, servo motor and driving
Cutting fluid system
Working light
Spindle
Auto lubrication system
Machine cover
Operation unit
4 position electronic turret+3 jaw chuck
Leveling pad
Manual tailstock
Tools and toolbox
Technical documents
Optional accessories:
3 jaw hydraulic chuck
Auto feed bar
