JOINT ZNC Micro Wire EDM Machine Die Sinking Making Metal Molds ZNC-700
Electric Discharge Machine ZNC-700
1. Have functions as Automatic Monitoring Level, Infra-red flame detecting, depth alarm and cutting off
electricity, finding the central point.
2. Adopt the MOSFET electrocircuit, with high speed processing
3. With positive-negative switch function. Anti-fighting functions can also be added to process particular molds.
4. making the modular surface more smooth and the fineness degree better
5. Dielectric fluid nozzles built in machine head that efficiently removes debris, saves time and is convenient.
6. Able to process deep holes, blind holes, lateral and large area machining.
1. Equiped with CAD, the machines are nondeforming after a long-time processing
2. In electro-discharge machining, can change discharge parameter at any time without affecting processing.
3. The slide rail adopts V-shape and horizontal alignment.
4. with unlimited automatic discharge and program setting, you can choose any selection for machining
5. After high wave echo heat treatment, the work surface has a good wear-resistance.
Machine specification:
| Model | ZNC-700 |
| Size of oil container |
1650*1100*630mm |
| Table size | 1050*600mm |
| X axis travel | 700mm |
| Y axis travel | 550mm |
| Z axis travel | 250mm |
| Electrode head | 380mm |
| Max distance from the electrode head to table | 850mm |
| Max load of electrode head | 200kg |
| Max load of table | 2000kg |
| Dimension |
2000*1710*2360mm |
| Net weight | 2950Kg |
| Filter container cube | 980L |
| Filter container net weight | 300Kg |
Electric cabinet specification:
| Model | ZNC Machine |
| Control mode and axis No. |
NC with close circuit/Singel Z axis control |
| Min setting value | 0.005mm(0.001) |
| Max setting value | 9999.995mm(9999.9999) |
| Coordination system | INC ABS |
| Screen | 15'' FTT |
| Control system | Industrial PC |
| Moving velocity of controller | 0.005mm per unit*1, *5, *10 |
| Procedure in store | 0-999 groups |
| Max current for processing | 50/75/100A |
| Input rated power | 5/6/10KVA |
| Max cutting processing speed | 360/56/700mm²/min |
| Consumption of electrode head | ＜0.2% |
| Best surface rough | 0.25μmpa |
| Dimension | 620*860*1850mm |
| Net weight | 210kg |
