10*50inch 3HP R8 Spindle Manual Vertical Turret Milling Machine
10*50inch Travel 3HP R8 Spindle Manual Vertical Turret Milling Machine
Feature
3E Spindle tolerance is 0.005mm.
Its milling head adopts 3HP motor, 16 steps speed pulley head, variable speed head is optional.
This type of model is taiwan parts assembled in China.
The treble swallowtail guide way is adopted on three axis, so it is easy to adjust and repair.
It is suitable for household appliances, daily necessities mold processing.
Specification
| Model | 3E |
| Table size | 1270*254*90mm |
| X axis travel | 880mm |
| Y axis travel | 395mm |
| Z axis travel | 360mm |
| Travel of spindle quill | 127mm |
| Max distance from the spindle nose to table | 400mm |
| Spindle rotation speed | 80-5440/(16Grades)/60HZ 66-4530/(16 Grades)/50HZ |
| Spindle Taper | NT30/R8 |
| Spindle Rated power | 3HP |
| Tilt angle Forward and backward | ±45°(±0° optional) |
| Tilt angel left and right | ±90° |
| Dimension | 1500*1700*2150mm |
| Net weight |
1200kgs |
Machine Picture
Standare Accessories
Way cover , Tool and tool box ,draw bar ,manual pump ,Working light
Optional Accessories
Three axis DRO , Two axis DRO, Clamping kit , NT30/NT40 Milling chuck , X axis power feed ,Coolant system
6 Vise ,8 Vise , Power bar , Z axis Elevator motor
Optional For Milling Head
Square type step Speed Variable Speed Milling head Inverter Speed Milling Head Step Speed Milling Head
Milling head
Why Choice JOINT machine ?
A:Chinese TOP 10 Brand of milling machine
B: 26 Years professional Machinery manufacturer
C. China HI-TECH Enterprise
D.SHENZHEN TOP Brand
