280mm Electrode Head 5KVA Electric Discharge Machine
Price:
NEGOTIATION
MOQ:
1 SET
Delivery Time:
NEGOTIATION
Brand:
JOINT
Product Description
ZNC-450 Electrical discharge vertical machine erosion die mould easy operation
EDM machine
| Model | ZNC450 |
| Size of oil container | 620*860*1850mm |
| Table size | 700*400mm |
| X axis travel | 455mm |
| Y axis travel | 360mm |
| Z axis travel | 200mm |
| Electrode head | 280mm |
| Max distance from the electrode head to table | 480mm |
| Max load of electrode head | 120kg |
| Max load of table | 1200kg |
| Dimension | 2050*2530*2400mm |
| Net weight | 1500kg |
| Filter container cube | 460L |
Electric cabinet
| Model | ZNC Machine |
| Control mode and axis No. | NC with close circuit/single z axis control |
| Min setting value | 0.005(0.001)mm |
| Max setting value | 9999.995(9999.9999)mm |
| Coordination system | INC ABS |
| Screen | 15'' FTT |
| Control system | Industrial PC |
| Moving velocity of controller | 0.005mm per unit*1, *5, *10 |
| Procedure in store | 0-999 groups |
| Max current for processing | 50A |
| Input rated power | 5KVA |
| Max cutting processing speed | 360mm²/min |
| Consumption of electrode head | ＜0.2% |
| Best surface rough | 0.25 |
| Dimension | 620*860*1850mm |
| Net weight | 210kg |
Products Character:
1. Full size machine could meet with mold processing requirement.
2. System stability and durability, high reliability, greatly improve the precision and quality of the mold.
3. All key parts are from Taiwan and Japanese top brands.
