Spindle Belt 10000rpm CNC Machining Center 7.5KW Short Nose
900*450 working table BT40 7.5KW short nose spindle Belt connection 10000rpm CNC machining center
Product advantage:
1. Whole machine cover: Fully closed cover of the machine whose outlook is nice and it is for convenient and safe operation.
2. Guide way cover: X, Y, Z direction are all use protection device to ensure that the screw and the guide is clean and accurate.
3. Three axis adots linear guide way, with characteristics of high rigidity, strong abrasion performance, and high accuracy which ensure the stability of the machine.
4. V85 can add rotary table to become 4 axis machine in order to process more complex mold.
4. It is suitable for complex, multi-process, high precision requirements, the need for a variety of types of common machine tools and various tools, tooling, after several clamping and adjustment to complete the processing of parts with appropriate batch.
OVERVIEW:
Specification Of Vertical machine center VMC-V85
| Model | Unit | VMC-V85 | ||
| Travel | X axis | mm | 800 | |
| Y axis | mm | 500 | ||
| Z axis | mm | 500 | ||
| Distance between spindle and table | mm | 170-670/120-620 | ||
| Working table | Table size | mm | 900*450 | |
| Max. Load of table | Kg | 500 | ||
| T slot | Pcs－mm-mm | 3-18-130 | ||
| Positioning accuracy | X/Y/Z axis | mm | 0.006/0.006/0.006 | |
| Repeated positioning accuracy | X/Y/Z axis | mm | 0.005/0.005/0.005 | |
| Spindle | Spindle rotation speed | Rpm | 10000/12000/15000 | |
| Spindle taper | BT40 | |||
| Diameter | mm | Φ140 | ||
| Rivet model | BT40 45° | |||
| Rapid movement | X/Y/Z axis | m/min | 48/48/48 | |
| Cutting feed | X/Y/Z axis | m/min | 15 | |
| Tool magazine | Umbrella type | Size | Tools | 20 |
| Too changing time (T-T) | Sec | 6 | ||
| Max. diameter/ length/weight of tool | mm | 100/150/8 | ||
| Max tool diameter (no tool adjacent) | mm | 180 | ||
| Arm type | Size | Tools | 24 | |
| Tool changing time (T-T) | sec | 2.8s | ||
| Max. diameter/ /length/weight of tool | mm | 80/200/8 | ||
| Max tool diameter (no tool adjacent) | mm | 150 | ||
| Total capacity of electric | KVA | 15 | ||
| Weight of machine |
Kg
|
4200 | ||
| Dimension | mm | 2450*2535*2660 | ||
Standard Accessories:
Fanuc/Mitsubishi/Syntech Controller system ; Full enclosed cover; Spindle encoder position system ; Three axis inner encoder feedback system
Auto lubrication system ; Pneumatic system ; RS232 Interface; Hand unit; 24T tool magazine; spindle oil cooler; Heat exchanger; Working light ; Tool and tool box and other optiomal accessories, such as chain type chip conveyor
Optional accessories:
1. Siemens controller or other controller system
2. Chain type auto conveyor
3. Ring spray spindle
4. BBT spindle
5. 15000rpm spndle
