Industrial Grade Outdoor LCD Touchscreen Monitor 27 inches Display High Brightness With Optical Bonding
· INTRODUCTION:
27'' High Brightness Outdoor LCD Display, IP65 Series, Maintenance-Free
BENEFITS:
· High Brightness LCD Screen with Optical Bonding
LCD backlight brightness 1000-3000nits: Brilliant, ultra-clear visuals even in direct sunlight, ensuring your content stands out anytime, anywhere.
Optical Bonding Technology: Enhanced sunlight readability and improved touch accuracy by eliminating air gaps. Also reduces internal reflections and strengthens the display surface.
· Intelligent Brightness Control Eco-Friendly
Intelligent Brightness Control: Automatically adjust the LCD screen brightness according to the ambient light brightness to save energy to the maximum extent.
Eco-Friendly Performance: Low power consumption meets today’s energy-efficiency expectations without compromising performance.
· Industrial Grade Panel
Industrial-Grade Wide Temperature Panel: Engineered to withstand extreme temperatures without blackening, maintaining stability in both hot summers and cold winters.
High Tni 105℃ Open Cell: The LCD features a high-TNI 105°C open-cell surface, providing enhanced heat resistance and durability for high-temperature applications.
Polarized Sunglasses Compatible
Thanks to QWP technology, viewers can enjoy full clarity even while wearing polarized lenses—no screen blackout.
· Full IP65, Maintenance Free
Full IP65 Waterproof & Dustproof: A fully sealed front and rear structure ensures complete protection against water and dust-perfect for all-weather, 24/7 outdoor operations
Maintenance-Free Design: No internal fans, no filters—just long-term reliable operation with minimal upkeep, lowering your total cost of ownership.
· Industrial Design Ultra-Thin Body
Sleek Ultra-Thin Body: Modern, narrow-bezel design supports both landscape and portrait installation, with a pure-flat back for seamless integration into any environment.
Specification
| Model | ITD27CMODIPWxx | |
| Panel | Size | 27" |
| Panel Technology | TFT-LCD (LC Tni 105°C) | |
| Aspect Ratio | 16:9 | |
| Resolution | 1920×1080 | |
| Brightness | 1000~3000cd/㎡ optional | |
| Contrast Ratio | 1000:1 | |
| Viewing Angle | 178/178 | |
| Surface Treatment | ||
| Lifetime | 50000Hrs | |
| Display Mode | Landscape/Portrait Supported | |
| Physical Appearance | Color | 16.7M |
| Material | Aluminum and Galvanized Iron Plate | |
| Surface Treatment | Outdoor Powder Spraying (Anti-Rust) | |
| Outline Dimension | 662.5×401×99mm | |
| N.W. | 25kg | |
| Package Dimension | TBA | |
| G.W. | TBA | |
| Mounting Hole | VESA 570×250mm | |
| Operation Environment | Operating Temperature | -25~60℃ |
| Operating Humidity | 10%--90% | |
| IP level | IP65 | |
| Protective Glass | 5mmTempered Glass (Touchscreen, AG, AR, Anti-UV optional) | |
| Power | Input | DC24V input (AC110~240V input optional) |
| Max. Power Consumption | Max. 80W | |
| Motherboard | Monitor Version | Default Waterproof I/O: HDMI Input×1(More Video inputs optional) |
| ARM Based Version |
RK3288/RK3399/RK3568/RK3576/RK3588 optional Default Waterproof I/O: USB×2, RJ45×1, WiFi(optional) |
|
| X86 Based Version | Intel Celeron J1900/J4125/J6412, Intel Core i3/i5/i7 Default Waterproof I/O: USB×2, RJ45×1, WiFi(optional) | |
