17.3" Fanless Zero Bezel Touch PC for Smart Factories | PCAP Multi-Touch | 24/7 Reliability
This industrial-grade 17.3" fanless panel PC features a true flat, zero-bezel front design with advanced 10-point PCAP multi-touch technology, making it ideal for HMI/SCADA applications and continuous 24/7 operation.
- True Flat, Zero-Bezel Front Design - Easy-to-clean seamless surface eliminates dust and debris accumulation around edges and corners, ensuring hygienic and low-maintenance operation
- Front Panel IP65 / NEMA 4 Protection – Robust sealed front design protects against water, dust, and harsh environmental conditions
- Rugged Aluminum Frame & Steel Rear Housing – Precision aluminum framing provides structural reinforcement along the edges, while the robust steel rear housing ensures excellent strength, heat dissipation, and long-lasting reliability in demanding industrial environment
- Flexible Customization Options – Supports various configurations including CPU platforms, interfaces, brightness levels, and mounting solutions to meet specific project requirements
- DC 24V, DC9-36V, AC100-240V, PoE
- High Brightness, Optical Bonding
- Anti-glare, Anti-reflective, Anti-finger, Anti-UV
- WIFI, 4G/5G, Bluetooth, GPS
- Web Camera, Speakers, RFID, NFC, Fingerprint, QR Reader, Thermal Printer, etc.
- VESA Mount, Desktop Stand
DISPLAY
|
Panel |
Cell Type/Glass Surface |
TFT |
|
Size/ Aspect Ratio |
17.3”/16:9 |
|
|
Active Area/ Pixel Pitch |
381.888(H) ×214.812(V)mm/0.1989 × 0.1989mm |
|
|
Native Resolution/ Colors |
1920×1080/16.7M |
|
|
Brightness/ Contrast |
300cd/㎡(500~1000 cd/㎡optional)/900:1 |
|
|
Response Time/ Viewing Angle (Typical) |
30ms/85/85/85/85 |
|
|
Light Source |
LED Backlight with 30000Hours’Lifetime |
SYSTEM
|
Item |
ARM Solution |
X86 Solution 1 |
X86 Solution 2 |
|
CPU |
ARM Quad Core Cortex-A17 RK3288, 1.8GHz (RK3399/RK3568/RK3588/RK3576 optional) |
Intel® Celeron J1900/J6412 2.0GHz |
Intel® Core i3/i5/i7 (4th~12th Generation or newer optional) |
|
Chipset |
Rockchip |
Intel Bay Trail SoC |
Intel SoC Chipset |
|
Memory |
2GB; 4GB/8GB Optional
|
Dual Channel, DDR3 1333/1600MHz Memory, Max.8GB; DDR4 SODIMM×1(Intel J4125/J6412) |
2×DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB DDR4 SODIMM ×2 (8th~12th gen.); DDR5 (optional≥12th gen.) |
|
Storage |
8GB; 16GB/32GB/64GB/128G Optional |
1×mSATA/1×SATA/1×M.2 |
1×mSATA/1×SATA/1×M.2 |
|
Graphics |
Supports max. 4K resolution |
Intel HD/UHD Graphics (By CPU) |
Intel HD/UHD Graphics (By CPU) |
|
I/O |
1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 1 × COM(Optional); 1 × TF Card Support 8~128GB |
1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM port max. 6; 1×Realtek ALC662 Line-Out /MIC IN |
1×VGA Output; 1×HDMI Output; 2×USB 3.0; 2×USB 2.0 max. 6; 2×COM max. 6; 1×Realtek ALC662 Line-Out /MIC IN |
|
LAN |
1×10/100/1000Mbps Ethernet |
1× 10/100/1000Mbps Ethernet (Dual LAN optional) |
1×10/100/1000Mbps Ethernet (Dual LAN optional) |
|
OS |
Android 7.1/11/12/13/14, or newer etc. Linux Ubuntu(optional) |
Win7/10, Linux Win 11(available for J6412) |
Win 7/10, Linux Win 11(available for 8th Gen. or Newer) |
GENERAL
|
Power |
Input Voltage |
DC 12V 2.0 |
|
Operation/Power Saving |
10~25W |
|
|
Environment Considerations |
Operating Temperature |
-10~60℃(-20~70℃optional) |
|
Storage Temperature |
-20~70℃ |
|
|
Relative Humidity |
10%~90%(non-condensing) |
|
|
Order Information |
13.3” Fanless Zero Bezel Panel PC with PCAP Touch Android OS/ITD13PPCT5KEx |
|
|
13.3” Fanless Zero Bezel Panel PC with PCAP Touch J1900/ITD13PPCT5KJ1 |
||
|
13.3” Fanless Zero Bezel Panel PC with PCAP Touch J6412/ITD13PPCT5KJ6 |
||
|
13.3” Fanless Zero Bezel Panel PC with PCAP Touch i3/ITD13PPCT5KI3 |
||
|
13.3” Fanless Zero Bezel Panel PC with PCAP Touch i5/ITD13PPCT5KI5 |
||
|
13.3” Fanless Zero Bezel Panel PC with PCAP Touch i7/ITD13PPCT5KI7 |
||
|
13.3” Fanless Zero Bezel Panel PC with Tempered Glass No Touch /ITD13PPCG1Kxx |
||
|
13.3” 1000nits Fanless Zero Bezel Panel PC with PCAP Touch/ITD13PPCT5HBKxx |
||
|
13.3” 1000nits Fanless Zero Bezel Panel PC with Tempered Glass No Touch /ITD13PPCG1HBKxx |
||
