High Reliability 19 Inch Industrial Panel Mount Monitor Scratch Resistant Steel Chassis
19 inch industrial panel mount touchscreen LCD monitor display IP65 front, embedded mount, vandal proof
ITD industrial panel mount LCD displays provide reliability, durability, and expected longer product life. The rugged all steel enclosures with robust aluminum alloy front bezel with thickness of 6mm thickness and highly-durable glass front surface provide the durability needed for demanding industrial environments. Industrial panel mount monitors come with industrial/commercial-grade LCD flat screen sizes, touchscreen interface, industrial analog and digital driver board, low power consumption, and scratch-resistant capabilities are ideal for system integrators, kiosks, process control, food processing equipment, machine control, human-machine interface, automation equipment, industrial/factory automation, in-vehicle use and marine applications.
BENEFITES
- Superior picture quality, stunning display
- Rugged Panel Mount Design
- NEMA 4X rated for wash-down applications
- High temperature, shock and vibration specs
- Tempered Glass or Touch Screen Window
- High Reliability with field MTBFs greater than 50,000 hours
- 1.5-year warranty!
|
Panel Mount LCD Monitor
|
|
| Model Name | ITD19PMN101 |
| IP Rating | N/A |
|
LCD Panel
|
|
| Screen Diagonal (Inch) | 19” |
| Display Active Screen Size (cm) | 376.3(H)×301.1(V) |
| Aspect Ratio | 5:4 |
| Physical Resolution | 1280×1024 |
| Maximum Resolution Supported | 1920×1080 |
| Colors | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 1000:1 |
| View Angels | 85/85/80/80 |
| Backlight/Backlight Lifetime | LED Backlight with 50000Hours'Lifetime |
|
Touch Panel
|
|
| Touch Options | Resistive, IR, PCAP, SAW |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
|
Input / Output
|
|
| Video Input | 1 × VGA |
| 1 × DVI-I | |
| 1 × HDMI | |
| Audio | 1 × PC-Audio |
| Touch Connector | 1 × USB |
| Power Connector | 1 × DC2.0 |
|
Operation
|
|
| Operating Temperature Range | -10~60°C (-20~70°C Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
|
Power
|
|
| Power Indicator | Green LED |
| Power Input | DC 12V |
| Power Consumption | 32.5W |
|
Order Information
|
|
| 19”Panel Mount LCD Monitor with Resistive Touch | ITD19PMT101 |
| 19”Panel Mount LCD Monitor with IR Touch | ITD19PMT201 |
| 19”Panel Mount LCD Monitor with SAW Touch | ITD19PMT301 |
| 19”Panel Mount LCD Monitor with PCAP Touch | ITD19PMT501 |
| 19”Panel Mount LCD Monitor with Tempered Glass | ITD19PMG101 |
