Daylight Readable Industrial Touch Screen Monitor 9.7” Water Resistance

Price Negotiable

Price: TBA

MOQ: 1PCS

Delivery Time: 5-15 Business Days

Brand: ITD/OEM

Product Description

9.7 inch SVGA, XGA Rugged stainless steel full IP66/IP67 waterproof touchscreen LCD monitor displays

ITD rugged full IP66 LCD monitors are environmentally sealed to NEMA 4/4X & IP65 ratings for applications where dirt, dust, moisture and water are present. Our Rugged Industrial LCD products are constructed from solid steel and stainless steel for corrosion resistance applications.

FEATURES

- Sunlight and Daylight Readable

- Touch Screen (PCAP, IR, Resistive optional)

- DC Vehicle/Marine Power Supply Support

- Waterproof All Weather Operation

- VGA and/or HDMI Inputs

- Brightness Control, Light Sensor (optional, 0-100%)

- Composite Inputs Optional(Camera)

Applications for Rugged Touchscreen LCD Monitors

- Food processing plant automation control

- Kitchen application

- Chemical plant or laboratory

- Liquor Factory

- Clinical area / pharmaceutical / medical

- Operating and monitoring in Oil, Gas & Energy industry

- Industrial automation control in slaughtering house

- Railway/Transportation

Full IP65/IP66 Touchscreen Monitor
Model Name	ITD09CMG1IP*1
IP Rating	Full IP65/IP66(IP67 optional)
LCD Panel
Screen Diagonal (Inch/cm)	9.7”
Display Active Screen Size (mm)	196.608(H) x 147.456(V)mm
Aspect Ratio	4:3
Physical Resolution	1024 x 768
Maximum Resolution Supported	1920 x 1080
Colors	16.7M
Brightness (cd/m²)	400nits
Contrast Ratio	600:1
View Angels	80/80/80/80
Backlight/Backlight Lifetime	LED Backlight with 50000 Hours’ Lifetime
Touch Panel
Touch Options	Resistive, PCAP
Touch Drivers	Windows, Linux, Android, Mac, Raspberry Pi
Input / Output
Video Input	1 × VGA
	N/A
	1 × HDMI(Optional)
Audio	N/A
Touch Connector	1 × USB(Optional)
Power Connector	1 × DC2.0
Operation
Operating Temperature Range	-10~60°C (-20~70°C Optional)
Humidity Range (RH)	10-90%
24/7/365 Use	Supported
Power
Power Indicator	N/A
Power Input	DC 12V
Power Consumption	9W
Order Information
9.7”Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum Housing	ITD09CMT1IPA1
9.7”Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum Housing	ITD09CMT5IPA1
9.7”Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel Housing	ITD09CMT1IPS1
9.7”Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel Housing	ITD09CMT5IPS1
9.7”Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum Housing	ITD09CMG1IPA1
9.7”Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel Housing	ITD09CMG1IPS1
