Stainless Steel Full Rugged LCD Monitor 10.4'' AR / AG Coating Treatment
10.4 inch SVGA, XGA Rugged stainless steel full IP65 waterproof touchscreen LCD monitor displays for industrial control
ITD rugged full IP66 LCD monitors are environmentally sealed to NEMA 4/4X & IP65 ratings for applications where dirt, dust, moisture and water are present. Our Rugged Industrial LCD products are constructed from solid steel and stainless steel for corrosion resistance applications.
FEATURES
- Sunlight and Daylight Readable
- Touch Screen (PCAP, IR, Resistive optional)
- DC Vehicle/Marine Power Supply Support
- Waterproof All Weather Operation
- VGA and/or HDMI Inputs
- Brightness Control, Light Sensor (optional, 0-100%)
- Composite Inputs Optional(Camera)
|
Full IP65/IP66 Touchscreen Monitor
|
|
| Model Name | ITD10CMG1IP*1 |
| IP Rating | Full IP65/IP66(IP67 optional) |
|
LCD Panel
|
|
| Screen Diagonal (Inch/cm) | 10.4” |
| Display Active Screen Size (mm) | 211.2(H) x 158.4(V)mm |
| Aspect Ratio | 4:3 |
| Physical Resolution | 800 x 600 |
| Maximum Resolution Supported | 1920 x 1080 |
| Colors | 16.7M |
| Brightness (cd/m²) | 300nits |
| Contrast Ratio | 600:1 |
| View Angels | 80/80/70/70 |
| Backlight/Backlight Lifetime | LED Backlight with 50000 Hours’ Lifetime |
|
Touch Panel
|
|
| Touch Options | Resistive, PCAP |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
|
Input / Output
|
|
| Video Input | 1 × VGA |
| N/A | |
| 1 × HDMI(Optional) | |
| Audio | N/A |
| Touch Connector | 1 × USB(Optional) |
| Power Connector | 1 × DC2.0 |
|
Operation
|
|
| Operating Temperature Range | -10~60°C (-20~70°C Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
|
Power
|
|
| Power Indicator | N/A |
| Power Input | DC 12V |
| Power Consumption | 9W |
|
Order Information
|
|
| 10.4”Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum Housing | ITD10CMT1IPA1 |
| 10.4”Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum Housing | ITD10CMT5IPA1 |
| 10.4”Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel Housing | ITD10CMT1IPS1 |
| 10.4”Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel Housing | ITD10CMT5IPS1 |
| 10.4”Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum Housing | ITD10CMG1IPA1 |
| 10.4”Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel Housing | ITD10CMG1IPS1 |
APPLICATION
