Rugged Stainless Steel Lcd Touch Screen Monitor Industrial Grade 12.1 Inch
12.1 inch industrial Rugged stainless steel full IP66/IP67 waterproof touchscreen LCD monitor displays for industry
ITD industrial waterproof IP65/66 LCD monitor is manufactured exclusively from stainless steel and is designed for use in locations that are exposed to harshly corrosive influences. The all-round protection of these IP65-compliant monitors also makes them ideally suited for areas requiring constant cleaning (e.g. food industry, chemicals industry, medical technology, plant engineering).
FEATURES
- Sunlight and Daylight Readable
- Touch Screen (PCAP, IR, Resistive optional)
- DC Vehicle/Marine Power Supply Support
- Waterproof All Weather Operation
- VGA and/or HDMI Inputs
- Brightness Control, Light Sensor (optional, 0-100%)
- Composite Inputs Optional(Camera)
Applications for Rugged Touchscreen LCD Monitors
- Food processing plant automation control
- Kitchen application
- Chemical plant or laboratory
- Liquor Factory
- Clinical area / pharmaceutical / medical
- Operating and monitoring in Oil, Gas & Energy industry
- Industrial automation control in slaughtering house
- Railway/Transportation
|
Full IP65/IP66 Touchscreen Monitor
|
|
| Model Name | ITD12CMG1IP*1 |
| IP Rating | Full IP65/IP66(IP67 optional) |
|
LCD Panel
|
|
| Screen Diagonal (Inch/cm) | 12.1” |
| Display Active Screen Size (mm) | 246.0(H) x 184.5(V)mm |
| Aspect Ratio | 4:3 |
| Physical Resolution | 800 x 600 |
| Maximum Resolution Supported | 1920x1080 |
| Colors | 16.7M |
| Brightness (cd/m²) | 300nits |
| Contrast Ratio | 700:1 |
| View Angels | 80/80/70/70 |
| Backlight/Backlight Lifetime | LED Backlight with 50000 Hours’ Lifetime |
|
Touch Panel
|
|
| Touch Options | Resistive, PCAP |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
|
Input / Output
|
|
| Video Input | 1 × VGA |
| N/A | |
| 1 × HDMI(Optional) | |
| Audio | N/A |
| Touch Connector | 1 × USB(Optional) |
| Power Connector | 1 × DC2.0 |
|
Operation
|
|
| Operating Temperature Range | -10~60°C (-20~70°C Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
|
Power
|
|
| Power Indicator | N/A |
| Power Input | DC 12V |
| Power Consumption | 20W |
|
Order Information
|
|
| 12.1”Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum Housing | ITD12CMT1IPA1 |
| 12.1”Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum Housing | ITD12CMT5IPA1 |
| 12.1”Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel Housing | ITD12CMT1IPS1 |
| 12.1”Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel Housing | ITD12CMT5IPS1 |
| 12.1”Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum Housing | ITD12CMG1IPA1 |
| 12.1”Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel Housing | ITD12CMG1IPS1 |
