Rugged IP67 Stainless Steel Industrial Panel Mount Touch Screen PC Intel J1900/I3/I5/I7

Price Negotiable

Price: TBA

MOQ: 1PCS

Delivery Time: 10-15 work days

Brand: ITD/OEM

Product Description

Rugged IP67 Stainless Steel industrial touch panel PC waterproof dust proof with boot logo Intel J1900/I3/i5/i7

BENEFITES

Exceptional quality and highly engineered industrial panel computer
High Performance Processor, Graphics, Memory and Power
Ruggedized levels of NEMA 12, 4X, 4, IP52, IP56, IP65 ratings from all directions
Solid steel and stainless steel or aluminum alloy enclosures
IP65 sealed, Full IP65 I/O connectors protect from any particles, water, and corrosive agents
Easy-to-install VESA(75/100mm) wall mounting
Optional touchscreens like resistive and PCAP
Flexible, reliable, and ruggedized for open platform HMI/SCADA
Long lasting product cycle for continuity thru all phases of project

Specs:

Model	ITD10PPCG1IPSJ1	ITD12PPCG1IPSJ1	ITD15PPCG1IPSJ1	ITD17PPCG1IPSJ1	ITD19PPCG1IPSJ1	ITD21PPCG1IPSJ1
Size	10.4” (4:3)	12.1”(4:3)	15” (4:3)	17” (4:3)	19” (4:3)	21.5” (16:9)
Active Area	211.2(W) x 158.4(H)	246.0(H) x 184.5(V)	211.2(W) x 158.4(H)	337.92(H) x 270.33(V)	376.32(H) x 301.06(V)	476.64(H)x248.25(V)
Contrast Ratio	500:1	500:1	700:1	1000:1	1000:1	1000:1
Resolution	800x600 or 1024x768	800x600 or 1024x768	1024x 768	1280 x 1024	1280 x 1024	1920 x 1080
Brightness	300nits	300nits	300nits	250nits	250nits	250nits
Viewing Angles	70/70/60/70	70/70/60/60	80/80/60/80	85/85/80/80	85/85/80/80	85/85/80/80
Backlight	LED	LED	LED	LED	LED	LED

SPECIFICATION

System	CPU	Intel® Baytrail Celeron Quad Core J1900 2.0GHz Processor
	BIOS	Award BIOS 4/8Mbit SPI Flash ROM
	Chipset	Intel® Baytrail SOC CPU Integrated
	Memory	1 x SO-DIMM, DDR3 1333MHz Memory, 2GB, Max.8GB
	Graphic Chipset	CPU integrated graphics HD and support 1080p
	Storage	64GB SSD or 500GB HDD
I/O	Serial Ports	1x COM (Optional)
	USB Ports	1 x USB 2.0(Waterproof Connector and Cable)
	Power Port	1 x 12V DC Jack(Waterproof Connector and Cable)
	LAN	1 x 10/100/1000Mbps Ethernet(Waterproof Connector and Cable)
	WIFI	Built-in, 802.11a/b/g/h (optional)
Touch Screen	Type	Projected Capacitive Touch Screen with 10 independent touch points
	Response Time	≤5ms
	Interface	USB or COM, default to USB
	Transparency	≥85%
	Lifetime	≥50,000,000 times/click
	OS Support	Windows CE/XP/7/8/10, Linux, Mac, Android
General	Power Input	DC 12V
	Power Switch	Optional
	Mounting Option	75 x 75/100 x 100mm VESA Mount
Operation/Power Saving	TBA
Operating Temperature	-10~60℃
Storage Temperature	-20~70℃
Operation Humidity	10%~90%(No Condensation)
OS Support	Windows 7/ Windows XP/ Windows 8/ Linux
Mounting Method	VESA, embedded/panel mounting with clamps, desktop stand
Order Information	Stainless Steel Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPSJ1
	Stainless Steel Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPSJ1
	Stainless Steel Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPSJ1
	Stainless Steel Full IP67 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPSJ2
	Stainless Steel Full IP67 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPSJ2
	Stainless Steel Full IP67 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPSJ2
	Aluminum Alloy Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPAJ1
	Aluminum Alloy Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPAJ1
	Aluminum Alloy Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPAJ1
	Steel Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPXJ1
	Steel Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPXJ1
	Steel Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPXJ1
