Wall Mounted Industrial Touch Screen Monitor 55" Flat Panel Aluminum Alloy Housing
Flat Panel industrial Touch Monitor 55" true flat capacitive multi touch panel aluminum alloy housing wall mounted
ITD new PCAP multi-touch screen monitor new series is fully-integrated, off-the-shelf unit that combines Projected Capacitive Touch Technology with vandal proof, in an industrial/commercial -grade LCD flat panel, with a sleek‚ IP65 NEMA 4, and true flat front surface industrial design. These multi-touch displays with HMI interface provide a full range of industrial-grade units with multi-function capabilities and brilliant displays.
BENEFITES
- All steel/aluminum construction provides rugged frame for public use environments
- Ten independent touch points, plug and play
- Eliminates dust and debris build-up at the edge and corners of the display
- Provides improved power efficiency and reduced consumption
- Responds to a light touch in activating response
- Easy-to-clean surface without bezels
- Long lasting product cycle for continuity thru all phases of project
|
Zero-Bezel PCAP Touchscreen Monitor
|
|
| Model Name | ITD55OFT5K1 |
| IP Rating | IP65 Front Panel |
|
LCD Panel
|
|
| Screen Diagonal (Inch/cm) | 55” |
| Display Active Screen Size (mm) | 1213.6(H) ×684.4(V) |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920×1080 |
| Maximum Resolution Supported | 1920×1080 |
| Colors | 16.7M |
| Brightness (cd/m²) | 400nits |
| Contrast Ratio | 3000:1 |
| View Angels | 89/89/89/89 |
| Backlight/Backlight Lifetime | LED Backlight with 50000 Hours’ Lifetime |
|
Touch Panel
|
|
| Touch Technology | Projected Capacitive Touch |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
| Touch Life | 50,000,000times/click |
| Surface Hardness | 7H |
|
Input / Output
|
|
| Video Input | 1 × VGA |
| 1 × DVI-I | |
| 1 × HDMI | |
| Audio | 1 × PC-Audio |
| Touch Connector | 1 × USB |
| Power Connector | 1 × DC2.0 |
|
Operation
|
|
| Operating Temperature Range | -10~60°C (-20~70°C Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
|
Power
|
|
| Power Indicator | Green LED |
| Power Input | AC100-240V |
| Power Consumption | Below 100W |
|
Optional
|
|
| Side Mounting Brackets, Desktop Stand, VESA Mounting Brackets, Webcam | |
|
Order Information
|
|
| 49”Non Touch Monitor with Tempered Glass | ITD55OFG1K1 |
