D1mm~50mm Sapphire JGS1/Bk7/Borosilicate Optical Glass Cylinder Rod, Endoscope Rod Lens
Price:
negotiable
MOQ:
1000pcs
Delivery Time:
7 days
Brand:
UNIFORM
Product Description
D1mm~50mm Sapphire JGS1/Bk7/Borosilicate Optical Glass Cylinder Rod, Endoscope Rod Lens
Optical Glass Guide Specifications:
- Materials:JGS1/Bk7/Borosilicate.
- Diameter range: 1-50mm
- Dimension tolerance: +/0.05mm,+/-0.1mm
- Thickness tolerance: +/-0.05mm,+/-0.1mm
- Parallelism: < 1arcsec(can change for different types and as required)
- Surface quality: 10/5(can change for different types and as required)
- Coating: Uncoated or Coated(as required)
| Diameter | 0.2-300mm or customization |
| Diameter tolerance | +/-0.1mm or +/-0.02mm |
| Thickness | 0.10-100mm |
| Thickness tolerance | ± 0.1mm or +/-0.02mm |
| Surface quality (scratch & dig) | 60/40, 40/20 or better |
| Surface accuracy | λ/10, λ/2, λ |
| Clear Aperture | >85%, >90% |
| Parallelism | +/-3' ,+/-30'' |
| Bevel | 0.1~0.3mm×45 degree |
| coating | AR, BBAR or upon customer request( UV, VIS, IR) |
FAQ:
1. . Could you send free samples?
Your samples fee will be returned when you plack bulk order.
2.What's the delivery time?
7 days, it is up to your quantity and soecification and our stock. If in stocks, once you make the payment, your products will be sent within 2 days.
5. Can you OEM or ODM?
Yes, we accept all OEM and ODM.
