Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L

Price Negotiable

Price: Negotiation

MOQ: Negotiation

Delivery Time: 3-20 days

Brand: Treering

Product Description

PT 10000L Plastic Roto Mold Tanks For Vertical Water Storage And Aquaculture For Liquids Storage

Desciption of the water tank

PT10000liter Vertival shape Plastic water tank , Made by rotomolding technique .

The rotational molding is a thermoplastic fabrication technique that manufactures hollow products by using

heat and a revolving metal mold. Rotomolded products are seamless, uniform in wall thickness and of

single construction, which eliminates costly fabrication processes and the need for replacement parts.

100% food grade plastic ----helps the water to retain its original characteristic over a period of time.

Half automic roto molded technology ----used to prepare the tanks in one piece so that there are no joints.

This prevents leakage and longevity of the tanks.

Inlet and outlet ports are located of flat surfaces which eliminate possibilities of leakage.

The tanks are available in various colours and are odour and fungus free.

Sepcification

Model

Capacity

Weight

Dimensions

Lid

Fitting

Specific Gravity

PT10000 l

2250 Gallon /10000L

300

2225*2800 mm

650

2″ -4"

1.0 -1.35

Mould	Capacity	Specification	Weight (kg)
PT200	200L	Diameter: 560mm Caliber :370 mm Heigh : 900 mm Plastic thickness :3mm	5.5
PT300	300L	Diameter: 720mm Caliber :450 mm Heigh : 920 mm Plastic thickness :3.5mm	10
PT500	500l	Diameter: 850mm Caliber :450 mm Heigh : 1100 mm Plastic thickness :4mm	15
PT800	800L	Diameter: 1000mm Caliber :450 mm Heigh : 1270 mm Plastic thickness :4.5mm	18
PT1000	1000L	Diameter: 1070mm Caliber :450 mm Heigh : 1400 mm Plastic thickness :5mm	25
PT1500	1500L	Diameter: 1210mm Caliber :450 mm Heigh : 1530 mm Plastic thickness :5.5mm	35
PT2000	2000L	Diameter: 1330mm Caliber :450 mm Heigh :1700 mm Plastic thickness :5mm	45
PT3000	3000L	Diameter: 1500mm Caliber :450 mm Heigh : 1880 mm Plastic thickness :6.5mm	70
PT4000	4000L	D1700*H2100 mm	100
PT5000	5000L	D1820*H2230 mm	120
PT6000	6000L	D12030*H2420 mm	160
PT8000	8000L	D12030*H3100 mm	200
PT10000	10000L	Diameter: 2250mm Caliber :650m Heigh : 2750m Plastic thickness :12.5	280
PT15000	15000L	D2680*H3030 mm	420
PT20000	20000L	D2700*H3950 mm	600
PT30000	30000L	D3100*H4300 mm	1000
PT4000	40000L	D3400*H5000mm	1500
PT50000	50000L	D3400*H6500 mm	1750
