110KV Substation Transformer Oil Regeneration Machine Two Stage Vacuum Pumps
Substation Necessary Maintainance Tool - Transformer Oil Regeneration Purifier with Vacuum System
I. Description of VFD-R
VFD-R Vacuum Transformer Oil Regeneration Purifier is especially applied to regenerate used and aging transformer oil, insulating oil. Especially for ultra high voltage like 110KV, 500KV, 1000KV. It can perform a perfect and super high efficient oil purification, oil filtration and oil recycling process to old transformer oil.
II. Features of VFD-R
- High vacuum limiting vacuum less than 5pa, working vacuum less than 35pa.
- High absorption speed, absorption speed power more than 333L/Sr.
- Carbon fiber infrared heating system that can make the oil contains zero sum of ethyne after treatment.
- The oil of any grades can be treated on line at the working site.
- The Automatic oil purifier model is installed with PLC (Programmable logical control system) which can control the equipment automatically to every stage of its process and ensure its process and ensure its safe operation on site and on line without human supervision.
- Can be operated both on-line and off-line.
- Equip with oil regeneration device to clean out the acidity matters from oil, refresh oil to be new.
III. VFD-R Can:
- Purifying your transformer oil high efficiently
- Maintain your transformer oil always in good status
- Save your old transformer oil replacement cost
- Solve your waste transformer oil disposal problem
- Guarantee your transformers working normally with qualified oil property
- Protect your transformers and power equipment from oil pollution problems
- Reduce your maintenance time, energy and invest on transformers and power plant
- Create a safety and cleaning oil use environment for your transformers of power station
- Bring a green oil ideal to the world and save oil energy for all of our generations
IV. Machine Specification
| Item | Unit | VFD-R-30 | VFD-R-50 | VFD-R-75 | VFD-R-100 | VFD-R-150 | VFD-R-200 | VFD-R-300 | |
| Flow Rate | L/H | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 | 18000 | |
| Working Vacuum | Mpa | (-0.092) ~ (-0.099) | |||||||
| Working Pressure | Mpa | ≤ 0.2 | |||||||
| Temp Range | ℃ | 20 ～80 | |||||||
| Power Supply | 380V, 50Hz, 3Phase or As per required | ||||||||
| Working Noise | Db | ≤ 72 | ≤ 78 | ||||||
| Heating Power | KW | 24 | 30 | 48 | 60 | 90 | 120 | 150 | |
| Total Power | KW | 29 | 36 | 56 | 69 | 100 | 132 | 170 | |
| Inlet/Outlet Diam | MM | 25 | 32 | 32 | 40 | 40 | 50 | 60 | |
| Weight | KG | 900 | 1100 | 1200 | 1450 | 1800 | 2000 | 2700 | |
| Size | L | MM | 1750 | 1900 | 1950 | 2700 | 3000 | 3200 | 3700 |
| W | MM | 1100 | 1200 | 1250 | 1400 | 1500 | 1600 | 1800 | |
| H | MM | 1700 | 1750 | 1800 | 1800 | 1850 | 1900 | 2000 | |
V. Oil Specification After Regeneration
| Dielectric Strength (BDV) | KV | ≥ 75 | |||||||
| Water Content | PPM | ≤ 3 | |||||||
| Gas Content | % | ≤ 0.1 | |||||||
| Particle Size | μ | ≤ 1 | |||||||
| Flash Point | ℃ | ≥ 140 | |||||||
| Acid Value | mgKOH/g | ≤ 0.01 | |||||||
| Cleanliness ≤NAS 1638 Grade 5 | |||||||||
About us:
►We are the leading manufacture near 25 years experience and supply best quality and highest cost performance oil purification machines. Our oil purifier equipment are built by high quality raw materials with newest advanced technology by many skilled technicians and professional workers. We are honest to every customer and responsible for every machine we sold, we offer great after sales service, anytime when customer need us, no matter before or after purchase, we are available online or calling, to make a fast and instant response to customer.
►we practiced in this industry during all these years, and have rich on-site experiences too. Any on-site cases, please contact us for a solution.
►For detailed product specifications, please leave us your email or mobile no. To send you the catalog. Thank you.
