Industrial Plate / Frame Portable Oil Purifier For Oil Cleaning Flow Rate 1800 L/H Easy Operation
PLATE AND FRAME FILTER PRESS
I. Application of LY series
NSH LY series Plate and Frame Filter Press Oil Purifier is specially apply in electricity factory, power station, transformer substation of mineral industry company, lubricant warehouse, tractor station, petroleum,chemical industry, metallurgy, national defense industry and so on, for purifying transformer oil, turbine oil, aviation hydraulic oil, and other liquid mixed water and impurities.
II. Features of LY series
- Mainly filtering impurities of transformer oil, turbine oil, engine oil, diesel oil, kerosene, aviation hydraulic oil.
- It also can be used for filtering edible oil while using stainless steel structure.
- Portable type,light weight, small volume, convenient to move.
- Simple structure,easy to operate and maintain.
III. Edges of LY series
Portable Oil Purifier LY series is characterized by simple structure,easy operation,low cost,etc.This machine is very efficiency to Filtering water and impurities from transformer oil, turbine oil, engine oil, diesel oil, kerosene, aviation hydraulic oil as well as coolant which made with stainless steel material.
IV. Technical Specification of LY series
| Model | LY-30 | LY-50 | LY-100 | LY-125 | LY-150 | LY-200 | LY-300 | ||
| Rated Current | L/min | 30 | 50 | 100 | 125 | 150 | 200 | 300 | |
| Working Pressure | Mpa | 0-0.5 | |||||||
| Filtering Area | ≥m2 | 0.3 | 0.39 | 1.3 | 1.54 | 1.89 | 2.01 | 3.1 | |
| Plate Dimension | Mm | 200*200 | 296*296 | ||||||
| Press Out | Manual screw | ||||||||
| Quantity of Filtering Room | 6 | 8 | 10 | 12 | 15 | 16 | 23 | ||
| Quantity of Filtering Plate | 7 | 9 | 11 | 13 | 16 | 17 | 24 | ||
| Oil Pump | Flow | L/min | >30 | >50 | >100 | >125 | >150 | >200 | >300 |
| Pressure | Mpa | 0.6 | |||||||
V. Other Series:
VFD series: Insulation oil purifier System specialize in purifying branded oil, insulation oil of high voltage and super high voltage transformer. Additionally, it is suitable for treating low viscosity lubrication oil.
TF series: Turbine oil purifier system is particularly suitable for purifying turbine lubricating oil. It also applys to treat hydraulic, coolant oil and other lubrication in which contain large of water, vapor, impurities, sludge, dielectric and colloid. It can eliminate them effectively and efficiently.
LV series: Lubrication Oil Filter System are suitable especially for purifying and restoring hydraulic oil, machine oil, coolant oil and various other lubrication oil.
GER series: Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used lubrication oil of machinery.
GED series: it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality.
