Touch Screen High Vacuum Oil Purifier For Dehydration Degassing Decloring

I. Application of Transformer Oil Filtration Machine

The NSH VFD series Multi-Function Transformer Oil Filtration Machine is an oil processing equipment designed to treat used transformer oil and give it a new life. The machine has the function of dehydrating, degassing, purifying, filtering and regenerating the transformer oil. Therefore, the moisture, gas and impurity contaminants in the transformer oil will be removed after being purified by our transformer oil filtration machine.


II. Features of Transformer Oil Purifier

In addition to filtering, purifying, and regenerating transformer oil, this machine can also be used for vacuuming and oiling the transformer.

III.Oil Data After Filtration

IV. Working Flow of Transformer Oil Purifier

1. The insulating oil is conveyed into the plant by means of pressure difference. Oil will firstly flow through a coarse filter, which can filter out large particles and mechanical impurities from insulating oil.

2. Oil is heated uniformly by electric heater with less specific heat transfer of 1.7w/cm², thus the deterioration of the oil caused by overheating is avoided during this process.

3. The special vacuum tank create a large oil surface and a resulting thin film, where the oil flows track and static water evaporation area were expanded to the largest extent, so that the effect of dehydration and degassing is maximized effectively. The particular double-stage vacuum pump system and pressure-boost technical make vacuum degree in vacuum tank higher than that in common oil purifier plant. Specially-designed oil level controller in the vacuum tank assures a continuous oil flow-through in the plant, thus resulting in an optimised dehydration and degassing of the oil. With the double-stage vacuum oil purifier, the installation period and maintenance period can both be shortened effectively.

4. After degassing and dehydration under vacuum, the oil is conveyed by through the fine filter and out of the plant.

5. Oil Circulation is recommended to achieve better effect of purification and filtration.

V.Machine Specification

VI. Available Style of Transformer Oil Purifier
1. Fixing type,mobile type with four wheels and mobile type with trailer.
2. Normal appearance type,shelf-covering type and explosion-proof type.
3. Avaliable in different color.
