Vacuum Turbine Oil Purifier Sino-NSH Model TF Oil Filtraiton For Turbine Oil
NSH Vacuum Turbine Oil Purifier
NSH-TF-E Explosion-Proof Turbine Oil Purifier
Sino-NSH-TF-E is Explosion-proof type designed for flammable and combustible working conditions in power plant, petroleum, petrochemical, chemistry, coal mining, metallurgy and other industries.
Sino-NSH-TF-E adds an explosion-proof system compare to NSH-TF, using comprehensive explosion-proof technology. The components such as heating system, electric control system, motor and solenoid valves etc are well-selected Explosion-proof type adapt to different danger level.
Technical data
| Parameter | Value | ||
| TF-150 | TF-300 | ||
| Capacity, liters/hour | 9000 | 18000 | |
| Heating Power, kW | 72 | 120 | |
| Total Power, kW | 78 | 129 | |
| Power Supply | Fully customizable | ||
| Inlet Diameter, mm | 40 | 65 | |
| Outlet Diameter, mm | 40 | 65 | |
| Dimensions (without trailer) |
length, mm | 1850 | 2400 |
| width, mm | 1250 | 1700 | |
| height, mm | 1610 | 1760 | |
| Weight (without trailer), kg | 750 | 1500 | |
| Processed Oil Spec | Water Content, ppm | ≤ 100 | |
| Cleanliness (NAS 1638) | ≤ 6 | ||
| Filtration Fineness, um | ≤ 5 (or 1-5 as needed) | ||
| Emulsification value, min | ≤ 15 | ||
Four main security and protecting systems:
1. Liquid level auto-controlling system
2. Auto pressure protection system
3.Steady temperature auto-controlling system
4.Electrical auto-protection system to control electric phases,voltage, and overload of pump
