50Hz Transformer Vacuum Oil Purifier Double Stage High Voltage For Degassing
Sino-NSH-VFD is a dehydration and degassing unit with thermal and double-stage vacuum processing.
Sino-NSH-VFD is mainly used to improve the properties of insulating oils in electric power transformers and other oil filled electrical equipment. It can remove dissolved and free water, dissolved gas and particulate impurities effectively so as to increase special indexes of insulation oil.
Sino-NSH-VFD combines vacuum flashing evaporation technology and delaminating gradual-close filter technology to reach best performance of oil purification. Meanwhile, by integrating efficient thermal and double-stage vacuum, the breakdown voltage is highly improved, which can be increased from 25kV to over 70kV.
Sino-NSH-VFD maintains an optimized structure and safe controls so as to meet comprehensive requirement of transformer manufacturers and service companies.
|
Paramater |
Value | |||||||
| VFD-30 | VFD-50 | VFD-75 | VFD-100 | VFD-150 | VFD-200 | VFD-300 | ||
| Capacity,liters/hours | 1800 | 3000 | 4000 | 6000 | 9000 | 12000 | 18000 | |
| Heating Power,kW | 24 | 30 | 48 | 60 | 90 | 120 | 150 | |
| Total Power,kW | 29 | 36 | 56 | 69 | 100 | 132 | 170 | |
| Power supply | Fully customizable | |||||||
| Inlet Diameter,mm | 25 | 32 | 32 | 40 | 40 | 50 | 65 | |
| Outlet Diameter,mm | 25 | 32 | 32 | 40 | 40 | 50 | 65 | |
|
Dimensions (without trailer) |
Length,mm | 1350 | 1500 | 1550 | 1900 | 2200 | 2400 | 2900 |
| Width,mm | 1100 | 1200 | 1250 | 1400 | 1500 | 1600 | 1800 | |
| Height,mm | 1700 | 1750 | 1800 | 1800 | 1850 | 1900 | 2000 | |
| Weight(without trailer),kg | 600 | 800 | 900 | 1500 | 1500 | 1700 | 2400 | |
| Processed Oil Spec | Water content,ppm | ≤ 5 | ||||||
| Dielectric strength,kv | ≥75 | |||||||
| Filtration fineness,um | ≤ 5(or 1-5 as needed) | |||||||
| Gas content,% | ≤ 0.1 | |||||||
Why choose us?
1. 27 years factory experience of lubrication purification machines.
2. Professional lubrication oil purifier engineers.
3. Your inquiry will be replied in 24 hours.
4. Secure good communication in English.
5. High quality, cheap price.
6. We also sell good after sales service.
7. Overseas service is avalable
8. On time delivery.
