Hydrophobic PTFE Industrial Water Filter Pleated Glass Fiber 10~50 Inch Long
liquid filter cartridge PP PTFE PES absolute hydrophobic PTFE pleated Glass Fiber
Description:
PP Pleated Filter Cartridge cater to high efficiency filtration requirement. They are constructed of high purity polypropylene materials which increasing dirt holding capacity. The materials comply with FDA related requirement.The high surface area enable high flow rates and long service life. The series of cartridge with multiple layered microporous ensure stable performance and broad chemical compatibility.
Specifications
Material of Construction
aa Filter Media: Polypropylene
aa Support : Polypropylene
aa Core / Cage / End adaptor: Polypropyle
PP Pleated Filter Cartridge
Material of Construction
• Filter Media: Polypropylene
• Support : Polypropylene
• Core / Cage / End adaptor: Polypropylene
• Sealing Technology: Thermal bonding
• Seal Material:Silicone,EDPM,Buna,Viton, Teflon,E-FKM
• Micron Rating: 0.1µm, 0.22µm, 0.45µm, 0.65µm,0.80µm, 1µm, 3µm, 5µm, 10µm, 20µm, 50µm
• Filtration Area: 0.5m2 each 10" length
Applications
• Pre-filtration for RO system
• Solvents, selected acids & lyes, chemical industry.
• Semiconductor, Electronic industry ultrapure water system
• Food and beverage
• Oil and Gas industry.
• Pharmaceutics
• Paints, coatings and plating solutions
Dimensions
• Outside diameter: 2.7” (69mm)
• Length: 5", 10", 20", 30", 40"
liquid filter cartridge PP PTFE PES absolute hydrophobic PTFE pleated Glass Fiber
| Construction Materials | Filter Media | GF |
| Support Layers | Polypropylene | |
| Inner core | Polypropylene | |
| Outer cage, End Cap | Polypropylene | |
| Seal Method | Thermal Bonding, No Adhesives | |
| O-rings/ Gaskets | Silicone/EPDM/Viton/PTFE/Nitrile | |
| Technical Data | Micron Rating | 0.45, 1.0, 3.0,5.0, 10 um |
| Operating Temperature |
Normal <60℃ (140 oF) Max. <85℃ (185 oF) |
|
| Normal Flow Direction pressure | 4.2 bar (60.9 psi) at 25℃ (77℉ ) | |
| Reverse Flow Direction pressure | 2.1 bar (30.5 psi) at 25℃ (77℉ ) | |
| pH Value Compatibility | 1-13 | |
| Sterilization | In-line steam sterilization is Not recommended, Flush with hot water at 82℃ (180 ℉ ) for 30 minutes | |
| Cartridge Size | Outer Diameter | Φ 69 mm(2.75’’) |
| Inner diameter | Φ 33 mm(1.30’’) | |
| Length(based on DOE end cap) | 10’’, 20’’, 30’’, 40’’ | |
| Filtration Area(m2) | 0.65 m2/10’’ | |
| Biosecurity | Endotoxin | <0.25 EU/ml |
| Extractable | ≤30 mg/10’’ | |
| Filtration efficiency | ≥90% | |
