Filter High Precision 1880cfm 18m2 F8 Gas Turbine Filters
R&D Capability
The R & D team is composed of more than 20 experts from various industries, which covers:
1. Research and development of air filtration materials.
2. The design of air filtration system / components process planning.
3. The design of air filtration system.
4. The design of automatic control system.
5. Simulation analysis of air filtration system.
6. ANSYS structure / thermal stress analysis.
7. CFD fluid dynamics simulation.
8. STAAD anti-seismic performance analysis.
|
Model |
O.D.(mm) |
H(mm) |
Rated air flow(Nm3/h) |
Initial resistance(Pa) |
|
97GT-3261 |
Φ320 |
610 |
900 |
140(M5-F7) 180(F8-F9) |
|
97GT-3266S |
Φ320 |
660 |
1000 |
140(M5-F7) 180(F8-F9) |
|
97GT-3266 |
Φ325 |
660 |
1000 |
140(M5-F7) 180(F8-F9) |
|
97GT-3270 |
Φ320 |
700 |
1100 |
140(M5-F7) 180(F8-F9) |
|
97GTZ-4066 |
Φ405 Φ325 |
660 |
1200 |
140(M5-F7) 180(F8-F9) |
|
97GTZ-4166 |
Φ410 Φ325 |
660 |
1200 |
140(M5-F7) 180(F8-F9) |
|
97GTZ-4466 |
Φ445 Φ325 |
660 |
1200 |
140(M5-F7) 180(F8-F9) |
|
Remarks: The above are regular model, other size can be customized. The end material and inner/outer mesh materials are will be same. |
||||
