AISI 321 Wires Ss Mesh Screen Netting Filter Dutch Weaving Flexibility
AISI 321 Stainless Steel Wire Netting Mesh Filter Screen
Product Description
SS 321 is a titanium stabilized austenitic chromium-nickel stainless steel which was developed to provide an 18-8 type alloy with improved intergranular-corrosion resistance. This material is stabilized against chromium carbide formation by the addition of titanium. Since titanium has a stronger affinity for carbon than chromium, titanium carbide precipitates within the grains instead of forming at the grain boundaries. 321 stainless steel should be considered for applications requiring intermittent heating between 800ºF (427ºC) and 1650ºF (899ºC), or for welding under conditions which prevent a post-weld anneal. 321 stainless steel is non-magnetic.
Material :SS 321 wires
Mesh: 1-200mesh
Weaving: plain and twill and dutch weaving
Stainless Steel 321 Mesh Chemical composition:
| C | Mn | Cr | Ni | Ti | P | S | Si | N |
| 0.08 | 2 | 17 – 19 | 9 to 12 | 0.70 | 0.040 | 0.030 | 0.75 % | 0.1 |
Mechanical Properties and Yield Strength of 321
| Property | Type 321 | Type 347 |
| Yield Strength, 0.2% Offset psi MPa |
30,000 205 |
30,000 205 |
| Ultimate Tensile Strength, psi MPa |
75,000 515 |
75,000 515 |
| Percent Elongation in 2 in. or 51 mm | 40.0 | 40.0 |
| Hardness, Max., Brinell (Plate) RB (Sheet & Strip) |
217 95 |
201 92 |
Characteristics of products/ Feature
- e and flexible
- Does not break
- Does not sag or roll up at the bottom
- Simple and artistic outlook
- Woven diamond pattern provides strong, durable and flexible construction.
Application
Used for industries of mining, oil, chemicals, food, pharmaceuticals, machine making, scientific research, aviation, etc
