Minerals & Metallurgy Wire Mesh Steel Wire Mesh
China 80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen for sale
China 80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen for sale
China 80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen for sale
China 80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen for sale
China 80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen for sale

80 100 Wire Mesh Filter Screen Silver Duplex Stainless Steel Filter Screen

Price Negotiable
Price: Negotiable
MOQ: 1 piece
Delivery Time: Within 5-8 working days
Brand: HC
Product Description

80 100 Mesh Duplex Stainless Steel Weave Wire Filter Mesh Screen



Product Description
60 70 80 90 100 mesh non-rusting weave duplex stainless steel Wire Mesh
Material
S31803(2205),S32750(2507), S32760
Mest count
plain weave can be woven from 1- 400 mesh
twill weave can be woven from 2- 635 mesh
dutch wevae can be woven up to 500*3500 mesh
Hole shape
square/round hole
Wire diameter
0.018-2.03mm
Stock size
1*30m/roll, 1.22*30m/roll, 1.5*30m/roll or customized



Application:

Mesh Demister, Oil&Gas Processor, Internal Combustion Engine, Dust Removing and Filtration etc.

Material: N4,N6

Specification:

350 Pin 0.153mmX2X1150X60m,350 Pin 0.153mmX1150X60m

Mesh hole size and filtration rate can be produced as per customer's request, normal mesh width: 25mm-600mm.

Property:

with anti-acid,anti-alkali,anti-high temperature,wear-resistant properties.



Plain Dutch Weave Stainless Steel Wire Mesh
NO
Mesh
Wire Dia(mm)
Aperture(um)
Weight(kg)
32#
8×62
0.63×0.45
300
5.42
40#
10×79
0.50×0.355
250
3.16
48#
12×64
0.58×0.40
280
2.9
55#
14×88
0.40×0.30
180
2.54
76#
19×140
0.315×0.20
140
1.88
80#
20×300
0.35×0.20
-
3.6
95#
24×110
0.355×0.25
120
2.45
100#
25×140
0.28×0.20
100
1.95
120#
30×150
0.25×0.18
80
1.68
140#
35×175
0.224×0.15
71
1.52
160#
40×200
0.20×0.14
60
1.40
180#
45×250
0.16×0.112
56
1.09
200#
50×250
0.14×0.11
53
1.04
220#
55.5×280
0.14×0.10
50
0.92
240#
65×330
0.11×0.08
36
0.71
280#(1)
70×350
0.11×0.08
35
0.72
280#(2)
70×385
0.11×0.07
32
0.75
300#
78×700
0.11×0.08
30
1.39
315#(1)
80×400
0.10×0.065
40
0.62
315#(2)
80×600
0.10×0.06
-
-
315#(3)
80×800
0.15×0.04
-
-
320#
81×780
0.10×0.07
30
1.22
354#
90×550
0.12×0.05
-
-



1.Materail: Stainless steel wire mesh 302/304/316/316L copper ,brass ,phosphor-bronze ,and special alloys ,nickel wire mesh ,titanium wire mesh ,monel wire mesh ,molybdenum wire mesh ,tungsten wire mesh ,zirconium wire mesh ,tantalum wire mesh ,inconel wire mesh ,nichrome wire mesh .

2.Weave type: Plain weave, Twilled weave, Dutch weave Twilled Dutch etc.



3.Width:According to the requirements.
Length: Normallly 30m/roll, or at customer request.
4.Features:Excellent Resistance Against Acid, Alkali, Heat and Corrosion Wear-resisting
5.Uses:Mainly used for filtering and sieving, extensively used in petroleum, chemical industry, enviroment protection, mine, airspace, paper-making, electronic, metallurgy etc.

Packaging & Shipping
Shipping port: Qingdao port,Shanghai port,Shenzhen port,Guangzhou port,Ningbo port,Tianjin port.
Delivery time: received payment within 2-5working days
Package details:

1. paper packing or plastic packing

2. carton packing
3. wooden packing
or acrroding to customer requirements.
Shipment:
By sea to your nearest port
By air to your nearest airport
By express (DHL, UPS, FEDEX, TNT, EMS) to your door




Stainless steel wire mesh is made of stainless steel wire 302, 304,316, 304L, 316L, with acidproof, alkali resistance, heat resistance, abrasion resistance, such as performance, is widely used in mining, petroleum, chemical,food,medicine,machinery manufacturing and other industries.
Our primary focus is the manufacture of woven wire mesh and cloth, especially in stainless steel, for industrial uses, chemical fiber, mining, filtration, and a wide range of uses. Stainless Steel Wire Mesh & Cloth, as an ideal filter medium, stands out when solutions for precise filtration and excellent corrosion resistance are needed. It excels in giving problem-free screening and is easily cleanable with excellent durability. The space wire weaves in square opening or rectangular openings can be woven down to a fineness of 5 micron aperture, also there are many combinations of filter weaves with retention in the micron range.
