Professional Nickel Mesh Screen Corrosion Resistance Nickel Chromium Wire

Monel Wire Mesh 400 , Monel 400 Woven Wire Mesh,60 mesh monel mesh screen

Production Introduction

Monel 400 material is a nickel-copper alloy (about 67% Ni – 23% Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Alloy 400 is a solid solution alloy that can only be hardened by cold working. This nickel alloy exhibits characteristics like good corrosion resistance, good weldability and high strength. A low corrosion rate in rapidly flowing brackish or seawater combined with excellent resistance to stress-corrosion cracking in most freshwaters, and its resistance to a variety of corrosive conditions led to its wide use in marine applications and other non-oxidizing chloride solutions. This nickel alloy is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. As would be expected from its high copper content, alloy 400 is rapidly attacked by nitric acid and ammonia systems.

Mechanical properties of monel alloy 400

UNS # - N04400

This 400 grade Monel is highly resistant to the corrosive action of acids, alkalides and salt water. It has the same strength of mild steel.

Chemical Composition:

C - 0.03%

Cu - Rem.

Fe - 2.5%

Mn - 2.0%

Ni - 63.0 - 70.0%

S - 0.024%

Si - 0.50%

Alloy K-500 is a nickel-copper super alloy with characteristics and corrosion resistance same as the alloy 400.Due to the addition of Aluminum and titanium alloy 500 offers greater strength and hardness than alloy 400.

chemical composition

Chemical composition

Ni:>63; Cu:27/33; Mn<1.5; Fe<2;Si<0.5; A1 2.3/3.15; Ti0.35/0.85

Mesh size of the Monel Mesh
