Product Parameter
Name	YN-1500	YN-2000	YN-2300	YN-Tunnel
Outside dimension(WxDxH)	1800x1500x2180	2000x1500x2180	2300x2000x2180	1800Wx4000Dx2180H
Inside dimension (WxDxH)	1300x1380x1980	1500x1380x1980	1800x1880x1980	1300Wx3880Dx1980H
SS Nozzle	18PCS	18PCS	24PCS	48PCS
Air velocity	22-27m/s	22-27m/s	22-27m/s	22-27m/s
Noise	<65	<65	<65	<65
(mm) Filter Size	610x610x90x2pcs	610x610x90x2pcs	610x610x90x4pcs	610x610x90x8pcs
Filter Efficiency	99.99%@0.3	99.99%@0.3	99.99%@0.3	99.99%@0.3
(W)Motor Power	1100x2pcs	1100x2pcs	550x4pcs	550x8pcs
(W)Light Power	8x1pcs	8x1pcs	8x2pcs	8x4pcs
Power Supply	380V/50Hz	380V/50Hz	380V/50Hz	380V50Hz



①Special ultra thin blowing tube housing and fan, match with rotatable embedded stainless steel nozzle, greatly increased the space utilization and blowing tube effect.

②High quality infrared sensor automatically showering;

③Time for showering can be adjusted from 0 second to 99 seconds, Adopts single chip microcomputer control, LCD display working status;

④Imported electronic interlock device, two doors can not opened at same time;

⑤With G1 and H13 99.99%@0.3 micron HEPA filter to ensure the purification class;

⑥Standard of the modular design, make field assembly faster and more convenient maintenance.

⑦But according to user needs and site condition transformation function and form.





 ①MINI-PLEATED HEPA FILTER
 Light weight, big air flow volume, long uisng life two stage filteration system ensure the clean class.



 ②SUPER HUGE AIR FLOW VOLUME AIR SHOWER ENGINE
 Supply air velocity more than 25m/s CE Certified, Safety Operation









YANING has a production workshop of more than 30,000 square meters,equipped with air filter,sheet metal, welding,spraying,assembly and other production workshops,equipped with advanced production equipment such as CNC equipment,laser cutting,automatic welding,etc.Under full commitment and management of more than 100 highly experienced and skilled engineers,we continue to provide customers with punctual,high-quality and cost-effective purification equipment.



YANING Purification always regards product quality as the life of the enterprise,and strives to provide customers with high-quality products and high-end services. After more than ten years of precipitation and development, the company has gradually formed a strong talent,technology and brand advantages. The diligent and sincere Yaning colleagues are willing to go hand in hand with you to create brilliancel!



The dust-free workshop can be roughly divided into 100,000, 10,000, thousand, hundred, ten classes. the higher the clean level, the more expensive the cost. The design and construction of a clean workshop requires professional technology and equipment to ensure the desired cleanliness and control effect.



The commonly used purification equipment in the dust-free workshop mainly includes: air filtration equipment (plate pre filter, medium pocket filter, HEPA filter), fan filter unit (FFU), air shower, pass box, clean workbench, etc.



Dust-free workshops are widely used in microelectronics, optoelectronics, electronic materials, instrumentation, precision machinery, pharmaceutical and biological engineering, food and beverage production and other fields. Our company provides one-stop service of clean workshop, including equipment research and development, design, manufacturing, sales, installation of clean technology solution integrated supplier.











1. Who are we?
We are based in Guangdong, China, start from 2011,sell to Domestic Market(60.00%),Southeast Asia(15.00%),North
America(10.00%),Western Europe(5.00%),Southern Europe(5.00%),Northern Europe(5.00%). There are total about 101-200 people in our
office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Air Shower, Fast Roll Doors, FFU, Operating Room, HEPA Filter,Clean Bench,Scrub Sink.etc.

4. Why should you buy from us not from other suppliers?
YANING brand clean room equipment:air shower pass box,clean bench,FFU,softwall clean room YANING brand Air
filters:HEPA,prefilter,pocket filter,V type filter Matched ISO14001,ISO9001,TUV,ROHS.CE,UL Best price and service,each products
strict facty test.

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
