Profesional 96pcs Wire 3150 Drum Twister Type Hv Armoured Cable Machine
96pcs Wire 3150 Drum Twister Type HV Armoured Cable Machine
1.Description
Drum Twister Type armoring machine is used for laying-up of large section, long length power cables. The line is for laying-up of pre-spiral or non-pre-spiral cable cores and Milliken cable. The line is used for steel wires armoring of power cables, too.
2.Main Specification
| Main Technical Data: | |||||
| Model | JPD-2500 | JPD-3150 | JPD-3600 | ||
| Max.cabling OD | Φ20~Φ120 | Φ25~Φ130 | Φ25~Φ130 | ||
| Max.rotation speed of T/U & P/O (RPM) | 50 | 30 | 30 | ||
| Cabling pitch | can be adjusted, step-less | ||||
| Max.Linear speed (m/min) | 50 | 40 | 40 | ||
| Max.pulling force | Standard | 3000 | |||
| Armoring with 96 steel wires | 5000 | ||||
| Central P/O reel | Φ2500 | Φ3150 | Φ3600 | ||
| P/O reel | Φ1600 | Φ2000 | Φ2500 | ||
| T/U reel | Φ2500 | Φ3150 | Φ3600 | ||
| Armoring steel wire reel | Φ500 | Φ630 | Φ630 | ||
| Main motor power (KW) | 45 | 55 | 75 | ||
| Central P/O motor power (KW) | 22 | 15 | 18.5 | ||
3.Main Parts
1 Φ2000 rotating pay-off stand(with lifting platform)
2 Pay-off stand of filling yearns
3 Guiding rollers stand
4 Three row cables assembly die set
5 Taping head (non-metallic tapes)
6 4T Rotating belt caterpillar (having meter counter)
7 Φ3150 rotating take-up stand with traverse(with lifting platform)
8 Electric transmission and control system
9 Pneumatic hydraulic system
10 Safe fences
11 2000 central pay-off
12 Steel wire pay-off syste,
