Low Price Supply Laying-up Machines Cradle Type Cable Laying Up Machinery
Price:
Negotiable
MOQ:
1 set
Delivery Time:
90 days
Brand:
Beyde
Product Description
Low Price Supply Laying-up Machines Cradle Type Laying up Machine Cable Laying up Machine
Laying up machine Application This series of products are suitable for the cabling and armoring of multi-core power cables of various cross-sections, cross-linked cables, and control cables. also available For the production of charging column cables.
|
Big bearing type Technical Parameter:
|
||
|
Model
|
1250
|
1600
|
|
Cage RPM(r/min)
|
21.3-50.9
|
11.8-28.3
|
|
Taping RPM(r/min)
|
289-644
|
289-644
|
|
linear Speed(m/min)
|
10.22-77.70
|
10.28-77.69
|
|
Normal type Technical Parameter:
|
|||
|
Model
|
1250
|
1600
|
2000
|
|
Inlet wire Dia.(mm)
|
8-40
|
10-60
|
15-70
|
|
laid up Dia.(mm)
|
80
|
120
|
140
|
|
Frame rotation speed(r/min)
|
13.9-33.1
|
8.0-18.5
|
4.0-8.8
|
|
Lay-up Pitch(mm)
|
181-3198
|
369-6646
|
400-6766
|
|
Taping speed(r/min)
|
188-419
|
188-419
|
150-334
|
|
Taping pitch(mm)
|
14.3-236.3
|
16-273
|
11-179
|
|
capstan Dia.(mm)
|
2000
|
2500
|
track
|
|
linear Speed(m/min)
|
6.00-44.41
|
6.78-51.21
|
3.53-26.86
|
Special launch Large bearing support, new high-speed cable forming machine, the main winch cage is changed from the traditional tugboat support to the large bearing support, supplemented by a series of changes in other aspects. Advance, make it higher speed, lower noise, no maintenance, better performance, more user-friendly operation.
