JPD-2000 Drum Type Twister , Instrument Cable Laying Up Machine
Price:
Negotiable
MOQ:
1 set
Delivery Time:
90 days
Brand:
Beyde
Product Description
Cable Laying Up Machine JPD-2000 Drum Type Twister For Instrument Cable
1. Application: This machine is mainly used for cabling large section and great length power cables and communication cables, and stranding of high voltage or extra high voltage Milliken conductors, and also for steel tape or wires armoring and copper tape or wires armoring.
2. Advantages:
1> High production efficiency: adopting new fork type structure for central rotary pay-off and rotary take-up machines, and hydraulic lifting platform for drums loading or unloading, this designing will enhance the rotating speed and shorten loading or unloading time.
2> Easy setting for traversing: the traversing pitches can be set, revised and displayed on the touch screen.
3> Rollers supporting: rotary take-up adopting rollers supporting, which can increase the rigidness and reliability of machines running.
4> Perfect safety protection system: adopting horizontal protection for pay-off and take-up machines, resetting protection for hydraulic lifting platform, over running protection for traversing, tape broken or finished protection for taping machines, safety protection covers, air pressure shortage protection, power off protection and so on.
5> Advanced electric control system: the rotary pay-off machines, taping machines, caterpillar haul-off machine, take-up machine and traversing adopting AC motors and inverter control, imported PLC to control and coordinate the whole production line, to ensure the synchronous running and the accuracy stranding pitches. Imported 10.4 inch colorful touch screen to set and display the whole line technical data.
| odel | JPD-2500 | JPD-3150 | JPD-3600 | |
| Max. laying-up OD | Φ20 –Φ120 | Φ25 –Φ130 | Φ25 –Φ130 | |
| Max. rotating speed of rum twister and pay-off stand | 50 | 30 | 30 | |
| Laying-up pitch | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
| Max. linear speed | 50 | 40 | 40 | |
| Max. haul-off force | Standard | 3000 | 3000 | 3000 |
| With 96pcs steel wire armoring | 5000 | 6000 | 6000 | |
| Non-metallic taping device | Max. speed | 500 | 500 | 500 |
| Taping pitch | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
| Tape reel | Φ600 xΦ80 | Φ600 xΦ80 | Φ600 xΦ80 | |
| Tape width | 15 - 80 | 15 – 80 | 15 - 80 | |
| Metallic taping device | Max. speed | 300 | 300 | 300 |
| Taping pitch | Step-less, adjustable | Step-less, adjustable | Step-less, adjustable | |
| Tape reel | Φ800 xΦ200 | Φ800 xΦ200 | Φ800 xΦ200 | |
| Steel tape width | 15 - 60 | 15 - 60 | 15 - 60 | |
| Central pay-off stand | PN2500 | PN3150 | PN3600 | |
| Pay-off stand | PN1600 | PN2000 | PN2500 | |
| Take-up drum head size | PN2500 | PN3150 | PN3600 | |
| Steel wire armoring specification | PND500 | PND630 | PND630 | |
| Main motor power | 45 | 55 | 75 | |
| Central payoff stand motor power | 22 | 45 | 55 | |
