11-20T Foton / Forland Chassis 270hp Stainless Steel SS304 Tanker For Water And Food Delivery
Price:
$36,500.00/units 1-4 units
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
FOTON | GET VEHICLES
Product Description
Product Description




Specification
|
Truck Model
|
|
BJ5182GSS-1
|
|
|
Main Parameters
|
Overall Dimension LxWxH mm
|
8310×2500×3200
|
|
|
|
Drive Type
|
42
|
|
|
|
Wheelbase mm
|
4600
|
|
|
|
Tread (F/R) mm
|
2010/1865
|
|
|
Weight Details
|
Tare Weight kg
|
7004
|
|
|
|
Capacity kg
|
10866
|
|
|
|
Passenge Carrier
|
3
|
|
|
|
G.V.Wkg
|
18000
|
|
|
Performace Parameters
|
MAX. Speedkm/h
|
89
|
|
|
|
Max. gradability%
|
38
|
|
|
Engine
|
Model
|
WP10.270E32
|
|
|
|
DisplacementL
|
9.726
|
|
|
|
/ Powerkw/rpm
|
199/270(2200
|
|
|
|
/ Max.TortueN.m/rpm
|
1100(1200-1600)
|
|
|
Transmission
|
Model
|
9JS119T-B(Q)
|
|
|
Clutch
|
Model
|
diaphragm spring clutch
|
|
|
Rear Axle
|
/ Model /Ratio
|
13Tdouble reduction/4.8
|
|
|
Suspension
|
/ Front
|
Longitudinal leaf spring + cylinder shock absorber,9
|
|
|
|
/ Rear
|
Longitudinal main and auxiliary leaf springs,9+6
|
|
|
Steering
|
|
AM75L
|
|
|
Brake System
|
Service brake
|
Double circuit pneumatic drum
|
|
|
|
Parking Brake
|
Energy storage spring air brake
|
|
|
|
Auxiliary brake
|
Engine exhaust brake
|
|
|
Tires
|
|
6+1/11.00R20
|
|
|
Fuel tank (L)
|
|
380
|
|
|
Others
|
|
Manual cab lift, airbag seat, manual rearview mirror glass lifter, air conditioning
|
|

|
A.TANK BARREL
|
|
|
||
|
1. Tank Profile
|
Round shape
|
|
||
|
2. Test pressure
|
Hydrostatic test to5 psi (35 Kpa) on each compartment. 5pas (35Kpa)
|
|
||
|
|
|
|
||
|
3. Working pressure
|
Atmospheric.
|
|
||
|
4. Capacity
|
10000L plus 3~5% ullage. 10000L+3-5%
|
|
||
|
5. Compartments
|
Single compartment.
|
|
||
|
6. Interior weld finish
|
Not polished or grinded (W-0).
|
|
||
|
7. Exterior weld finish
|
Not polished or grinded (W-0).
|
|
||
|
8. Shell material
|
Stainless steel 304 2B. 304 2B
|
|
||
|
a) Top
|
3.7mm nominal. 3.7mm
|
|
||
|
b) Sides
|
3.7mm nominal. 3.7mm
|
|
||
|
c) Bottom
|
3.7mm nominal. 3.7mm
|
|
||
|
9. End Plate
|
Stainless steel 304 2B, 3.7mm nominal. 3.7mm
|
|
||
|
|
All single heads dished and flanged.
|
|
||
|
10. Bulkhead
|
Nil.
|
|
||
|
11. Baffle / Surge Heads
|
Stainless steel 304 2B, 3.7mm nominal. 3.7mm
|
|
||
|
|
Dished with flap.
|
|
||
|
|
2 pcs.2
|
|
||
|
12. Spill molding and rollover protection
|
Stainless steel around the dome with drain hose.
|
|
||
|
13. Spill molding lids
|
Nil.
|
|
||
|
14. Outer rings
|
304-2B stainless steel, 60mm height, 3mm nominal, continuously welded. 304 2B 60mm3mm
|
|
||
|
|
|
|
||
|
15. Frame
|
Carbon steel independent.
|
|
||
|
16. Loaders and brackets
|
Carbon steel.
|
|
||
|
|
|
|
||
|
15. Isolation
|
Nil.
|
|
||
|
16. Exterior lining
|
Nil.
|
|
||
|
B. TANK FITTINGS AND PIPING
|
|
|
||
|
|
|
|
||
|
1. Manholes
|
20" diameter with 6 stainless steel wing nuts, located at the top center
|
|
||
|
|
1 pc. 2061
|
|
||
|
2. Pressure Vacuum Vent
|
Two per compartment. 6~12 kPa pressure, 2~4 kPa vacuum.
|
|
||
|
|
26~12 kPa , 2~4 kPa
|
|
||
|
|
Chinese Brand
|
|
||
|
|
|
|
||
|
6.Foot valve
|
Nil.
|
|
||
|
7. Discharge system
|
3 diameter discharge with 3" diameter butterfly valve, 3" stainless steel male camlock coupling and quick cap, located at the back
of the tank. |
|
||
|
|
|
|
||
|
8. Piping
|
Nil.
|
|
||
|
9. Thermometer
|
Nil.
|
|
||
|
10. Steam trace
|
Nil.
|
|
||
|
11. Overfill Prevention
|
Nil.
|
|
||
|
12. Tow Hook
|
Nil.
|
|
||
|
13. Product Indicators
|
Nil.
|
|
||
|
|
|
|
||
|
C. ACCESSORIES
|
|
|
||
|
1. Ladder
|
Stainless steel, 400mm wide, with non skid rungs and lateral handles, mounted at right middle of tanker. 400mm
|
|
||
|
|
|
|
||
|
2. Walkway
|
Extruded aluminium around dome.
|
|
||
|
|
|
|
||
|
3. Hose Carries
|
1 no, hose carrier (round tubes) to fit 159 x 6meter (236") hose close type complete with brackets to be installed at the right
side. |
|
||
|
4. Hose
|
Firemen type flexible discharge hoses, 30m 2.5" for discharge. and flexible plastics suction hoses, 5.9m 3"for suction, 3" female
camlock coupling at both ends. 2.530 |
|
||
|
5. Motor Pump
|
BRIGGS & STRATTON Gasoline motor , 4 stroke motor, fuel tank capacity 4.0 liters of gasoline, WB30 pump with a 3" input and outlet
diameter, 7m suction head, discharge capacity 900L/min (238Gal/min) pump head pressure 33 m, weight 30kg. +WB 30 |
|
||
|
6. Toolbox
|
Nil.
|
|
||
|
7. Rear Bumper
|
Aluminium member to accommodate light assembly and number plate to cover full width of the tank.
|
|
||
|
|
Steel bumper with ground clearance 500mm approx.
|
|
||
|
|
500mm
|
|
||
|
9. Hazchem Plate
|
Nil.
|
|
||
|
10. Mudguard
|
Aluminum over suspension and the upper coupler.
|
|
||
|
|
Mud flaps rigid plastic at the rear.
|
|
||
|
11. Lights & Wiring
|
24V. ISO 1185 7 pin socket. 24ISO 1185
|
|
||
|
|
Harness: oil and vapour proof cable.
|
|
||
|
|
Front: nil.
|
|
||
|
|
Side:
|
|
||
|
|
Mark lamp 3Pcs/side, LED.3LED
|
|
||
|
|
Reflector 3Pcs/side 3
|
|
||
|
|
Turning lamp 1Pcs/side, LED.1
|
|
||
|
|
Rear Bump:
|
|
||
|
|
Reverse lamp R-L 2Pcs, LED. 2
|
|
||
|
|
Turning lamp R-L 2Pcs, LED. 2
|
|
||
|
|
Brake lamp R-L 2Pcs, LED. 2
|
|
||
|
|
Register plate light
|
|
||
|
|
Rear top: nil.
|
|
||
|
|
Brand of Wiring: Phillips
|
|
||
|
|
|
|
||
|
12. Reverse alarm
|
Nil.
|
|
||
|
13. Connector Box
|
At the center in the front dishend
|
|
||
|
14. Sticker
|
50mm wide red-white reflective sticker, mounted at both sides and rear bump. 50mm
|
|
||
|
15. Hand rail
|
Nil.
|
|
||
|
16. Fire Extinguisher
|
8kg , 2Pcs. 8
|
|
||
|
|
Carbon steel extinguisher holder located on the landing gear on the curb side.
|
|
||
|
17. Drains hose
|
water drains hose 2", installed at the back of spill molding2
|
|
||
|
|
|
|
||
|
18. Wheel chocks
|
Nil.
|
|
||
|
19. Traffic cone
|
Nil.
|
|
||
|
21. Spare wheel bracket
|
1set
|
|
||
|
|
Carbon steel, basket type, located behind the landing gear.
|
|
||
|
21. Painting
|
Polyurethane medium Aluminium gray, applied over epoxy primer on carbon steel elements
|
|
||
Packing & Delivery
