Self-Propelled/Trailer Rvs Fw1 Single Front Window for RV Truck Camper Motorhomes DIY
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Features
Its unique features are beautiful appearance, large lighting area, double hollow acrylics for sound and heat insulation, UV resistance and good waterproof performance.
Technical Parameters
| Hinge | Made from high strength aluminum alloy. |
| Glass | Double hollow acrylics, UV resistance and dark grey color. |
| Flyscreen | Pleated flyscreen. |
| open | Push out the telescopic rod. There are two gear positions. After the third push, the gear is released and pulled back. |
| Special Note | Blind cover needs to be produced by customers according to their inner decoration. |
| Installation | FW1 can be used tog with PRW02 as a panoramic windows. Suitable for wall thickness: 31-32mm, 36-37mm. |
Specifications
| Type H x W | Acrylic size H1 x W1 | Cut hole (H+3) x (W+3) | Weight |
| mm | mm | Kg | |
| GET.FW1-700x1174 | 861x1279 | 703x1177 | 7.3 |
Technical drawing
