750W Meanwell Modular LED Flood Light ASS CE CB TUV GS 1 TO 10V DALI For Sports Ground Display
Price:
Negotiated
MOQ:
2PCS
Delivery Time:
5-15 Bussiness Day
Brand:
DUALRAYS
Product Description
100W LED Floodlights Symmetrical 30 to 90 Degree DALI SPD 20KV For Football Display
Options:
> Driver: Sosen,Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
> Microwave Motion Sensor;
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 2]()
> Airports & Harbors
> Billboard illumination
> Large recreational sports facilities
> Industrial areas & Landscape buildings
> Roundabouts and motorway junctions
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 3]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 4]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 6]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 7]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 8]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 9]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 10]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 11]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 12]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 13]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 14]()
![Outdoor IP65 50W 120LPW SMD3030 led security flood light 15]()
|
Model No.
|
DR-FL050-CGXX | DR-FL100-CGXX | DR-FL150-CGXX | DR-FL200-CGXX | DR-FL300-CGXX |
|
System Watts/W
|
50W | 100W | 150W | 200W |
300W
|
|
System Efficiency/LPW
|
120~125LPW | ||||
|
Lumen Output/lm
|
6.500±5% | 12.500±5% | 18.750±5% | 25.000±5% | 37.500±5% |
|
Rated Input Voltage/V
|
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional) | ||||
|
LEDs Light Source
|
SMD3030 | ||||
|
SDCM
|
<5 | ||||
|
CCT/K
|
5000K for Standard (3000K/4000K/5700K/6500K Optional) | ||||
|
CRI/Ra
|
>70Ra (>80Ra for Option) | ||||
|
Power Factor
|
>0.95 | ||||
|
THD
|
<10% | ||||
|
Beam Angle(Optional)
|
Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional | ||||
|
UGR
|
<25 | ||||
|
Surge Protection
|
6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional | ||||
|
LED Driver
|
Sosen,Meanwell ELG / HLG Optional | ||||
|
IP Rating
|
IP65 | ||||
|
Dimming(Optional)
|
1-10V, DALI,PWM,Zigbee for Option | ||||
| Safety Protection | Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection | ||||
| Sensor (Optional) | Motion Sensor | ||||
|
Protection Class
|
ClassⅠ | ||||
|
Finishing Color(Optional)
|
Black RAL9017(Standard) / White RAL9016 Optional | ||||
|
Material
|
Aluminum+Toughened Glass | ||||
|
Lifespan/hrs
|
62.000 Hrs (Ta=30℃@L70) | ||||
|
Operation Temp/℃
|
40°C to + 50°C(-40°F to 122°F) | ||||
|
Storage Temp/℃
|
- 40°C to + 65°C(-40°F to 149°F) | ||||
| Switching Cycles | 100,000 Times | ||||
|
Certificate
|
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available | ||||
|
Character/Power
|
100W
|
150W
|
200W
|
240W
|
300W
|
 |
|
A / mm
|
389
|
389
|
437
|
493
|
582
|
|
|
B / mm
|
297
|
297
|
346
|
379
|
444
|
|
|
C / mm
|
57
|
57
|
57
|
57
|
60
|
In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
(Partnership)
Q1: What is the warranty for the F4 flood light?
RE: For the F4 Series SMD LED flood light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.
Q2: What is colour temperature?
Q2: What is colour temperature?
RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:
the warmer the light given by the LED:
Warm white = 3000±200K
Natural white = 4000±200K
Pure white = 5000±200K
Cool white = 5700±200K
Q3: What‘re the chips and drivers used?
RE: High brightness LUMILEDS LEDs light source,Meanwell/Sose drivers for standard configuration.
Q4: What is the CRI?
Q7: Finish color?
Q4: What is the CRI?
RE: Ra>70 for standard.
Q5: IP Rating?
RE: IP65.
Q6: Labeling ?
Q6: Labeling ?
RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).
Q7: Finish color?
RE: Standard colors: Black / White,other colors can be customized, based on MOQ 50PCS.
|
Model No.
|
Net Weight/Kg
|
Outer Carton Size/mm
|
Gross Weight/Kg
|
QTY”/CTN
|
|
DR-FL050-CGXX
|
3.6
|
355*350*165
|
4.5
|
1PCS/CTN
|
|
DR-FL100-CGXX
|
3.8
|
355*350*165
|
4.7
|
1PCS/CTN
|
|
DR-FL150-CGXX
|
4.5
|
415*410*175
|
5.8
|
1PCS/CTN
|
|
DR-FL200-CGXX
|
5.7
|
475*470*195
|
7.3
|
1PCS/CTN
|
|
DR-FL300-CGXX
|
9.3
|
475*470*195
|
11.5
|
1PCS/CTN
|
