IP65 1500W IK08 LED Sports Ground Flood Lights diffuser High Power 5 Years Warranty
IP65 1500W IK08 LED Sports Ground Flood Lights High Power With 5 Years Warranty
> Efficiency : 130~140LPW,150~160LPW
> Light Glare: Shield;
|
Model No.
|
DR-SPL300-DGXX | DR-SPL600-DGXX | DR-SPL900-DGXX | DR-SPL1200-DGXX | DR-SPL1500-DGXX | DR-SPL1800-DGXX |
|
System Watts/W
|
300W | 600W | 900W | 1200W | 1500W |
1800W
|
|
System Efficiency/LPW
|
130~140LPW / 150~160LPW Optional | |||||
|
Lumen Output (Max) /lm
|
48.000±5% | 96.000±5% | 144.000±5% | 192.000±5% | 240.000±5% | 288.000±5% |
|
Rated Input Voltage/V
|
AC200~240V, 50/60Hz | |||||
|
LEDs Light Source
|
SMD3030 / SMD5050 | |||||
|
SDCM
|
<5 | |||||
|
CCT/K
|
5000K for Standard (3000K/4000K/5700K/6500K Optional) | |||||
|
CRI/Ra
|
>70Ra (>80Ra for Option) | |||||
|
Power Factor
|
>0.95 | |||||
|
THD
|
<10% | |||||
|
Beam Angle(Optional)
|
Symmetrical 25°/40°/50°/90° beam angle optional | |||||
|
UGR
|
<25 | |||||
|
Surge Protection
|
4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional | |||||
|
LED Driver
|
Meanwell ELG/HLG | |||||
|
IP Rating
|
IP65 | |||||
|
Dimming(Optional)
|
1-10V, DALI,PWM,Zigbee | |||||
| Safety Protection | Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection | |||||
| Start Time | 0.5s | |||||
|
Protection Class
|
ClassⅠ | |||||
|
Finishing Color(Optional)
|
Black RAL9017(Standard) / White RAL9016 Optional | |||||
|
Material
|
Aluminum+PC | |||||
|
Lifespan/hrs
|
70.000 Hrs (Ta=30℃@L70) | |||||
|
Operation Temp/℃
|
40°C to + 50°C(-40°F to 122°F) | |||||
|
Storage Temp/℃
|
- 40°C to + 65°C(-40°F to 149°F) | |||||
| Switching Cycles | 100,000 Times | |||||
|
Certificate
|
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available | |||||
|
Model No.
|
Net Weight/Kg
|
Outer Carton Size/mm
|
Gross Weight/Kg
|
QTY”/CTN
|
|
DR-SPL300-DGXX
|
4.2
|
650*240*250
|
4.8
|
1PCS/CTN
|
|
DR-SPL600-DGXX
|
4.2 |
650*240*390
|
8.2
|
1PCS/CTN
|
|
DR-SPL900-DGXX
|
10.9
|
650*240*540
|
12.4
|
1PCS/CTN
|
|
DR-SPL1200-DGXX
|
14.3
|
650*240*690
|
15.8
|
1PCS/CTN
|
|
DR-SPL1500-DGXX
|
17.6
|
650*240*850
|
19.8
|
1PCS/CTN
|
|
DR-SPL1800-DGXX
|
23.1
|
650*240*980
|
25.4
|
1PCS/CTN
|
FAQ
Q1:Where is the value of floodlights?
1) Adopting advanced light distribution design technology, the projection interval is far, and the light is mild and average.
2) It has good electromagnetic compatibility and will not disturb the power transmission network.
3) The optimized structure design and high-strength alloy shell make the product have the ability to resist strong collision and impact.
4) Using high-efficiency gas discharge lamp as the light source, it has high brightness and long life. The average service life can reach more than 10,000 hours.
5) Adopting multiple anti-vibration structure design, superior anti-seismic performance, can be used in various high-frequency vibration environments.
6) It has an integrated structural design, beautiful and generous, simple and convenient installation, and can adopt various installation methods such as seat type, wall hanging, ceiling and so on.
7) It adopts environmentally friendly light alloy materials, high-tech spraying technology, dustproof, waterproof, corrosion-resistant and rust-proof, suitable for long-term outdoor work.
