6 To 30 Millimeter Width Double Glazing Hot Melt Butyl Extruder CE Approved
Butyl Coating Extruder Machine Double Glazing Equipment With Touch Screen With Simple Butyl Cylinder Device
Features
1.Butyl extruder can process frames from 6-30mm width.
2.The feeding nozzle can be positioned to deliver uniform sealing.
3.Adopt Germany pneumatic pump,brand Maximator.
4.Can seal the circle aluminum
5.The height adjustment is available according to the frame size.
6.The nozzle width shall be controlled by pneumatic and hydraulic parallel method.
7.Pneumatic operation of butyl process is controlled by a PLC that electrically regulates the temperature of the butyl heaters.
8.Possible to control the length of butyl application and monitoring current production quantity on the touch screen.
9.A timer enables the pre-heating of butyl ahead of the start of operation.
10.Conveyor speed can be adjusted with 5 conveyor speed.
Main components
| Name | Brand | Original |
| PLC | KINCO | China |
| Valve | HAWE | German |
| Low voltage electrical apparatus | SIEMENS | German |
| Hydraulic and pneumatic supercharging system | MAXIMATOR | German |
| Frequency converter | KINCO | China |
| Pneumatic components(cylinder/valve) | ARTAC | Taiwan |
| Quick exhaust valve/Vacuum generator | SMC | Japan SMC |
| Travel light | OMRON | Japan |
| Optical fiber | OMRON | Japan |
Machine details
Main parts
Special Material Belt:
Using TEFLON non-adhesive belt,keep clean.
Sensor:
Automatically measure the width of frame.
TEFLON glue nozzles:
Adopt Teflon non-adhesive glue nozzles, keep spreading quickly.
