Curtain Wall Double Glazing Equipment , Glass Production Line Touch Screen Operating
Curtain Wall Double Glazing Equipment , Glass Production Line Touch Screen
LJBZ 2535 Automatic vertical Insulated glazed glass production line uses advanced technology to make high-quality and variety IG automatically, such as double glass, triple glass, shaped glass and stepped glass.
| Model | Min size of glass(Optional) | Max size of glass | Low-E | Stepped glass | Triple glass | Gas filling online |
| LJBZ1825 | 300*500 | 1800*2500 | Available | Available | Available | Available |
| LJBZ2025 | 300*500 | 2000*2500 | Available | Available | Available | Available |
| LJBZ2230 | 300*500 | 2200*3000 | Available | Available | Available | Available |
|
LJBZ2535 (Optional) |
300*500 | 2500*3500 | Available | Available | Available | Available |
| Max.glass size | 2500*3500mm/2200*3000mm/2000*2500mm |
| Min.glass size | 280*450mm |
| Glass thickness | 3-15mm |
| Insulating glass thickness | 60mm |
| Glass washing speed | 2-10m/min |
| Glass conveyor speed | 48m/min |
| Washing brushes | 3 pairs |
| Water supply | Water consumption:0.5t/h conductivity:≤50μs/cm |
| Air supply | Flow: 0.8m/min |
| Air pressure | ≥0.8MPa |
| Total power | 3P 380V 50HZ 40KW/27KW/24KW |
| Dimension | 23500*3500*3700mm/18350*2600*3250mm/16400*2500*3100mm |
| Weight | 6500kg/6000kg/5200kg |
Main features:
- Self-diagnosis system with touch screen on computer
- Stainless steel washer with 6 brushes, soft brushes from, hard brushes automatically open when Low-E glass input
- Rotate speed of brush frequency control(optional)
- Stainless steel air knife is automatically adjustable according to glass thickness, Max thickness to 19mm
- High speed cleaning ( max 14m/min), Low noise ( max 70dB), high availability working ( 25 second /unit)
- Automatic detection of Low-E glass and alarm for coating in reverse(optional)
- Structure stepped and three-layer I.G. unit available(optional)
Main conditions:
- Product Name: IG Production Line
- Keyword: Insulating glass production line
- Place of orign:Jinan
- Input Voltage: 380v
- Max glass size: 2500*3500 mm (Optional)
- Working Speed: 50m/min
- Min glass size: 300*500mm
- Condition: Double glazed glass production line
- Machine Type: IG machines
- Production Capacity: 50m/min
- Place of Origin: Shandong
- Brand Name: Jinan
- Model Number: LJBZ
- Voltage: 380V
- Certification: CE
- Warranty: 1 Year
- After-sales Service Provided: Engineers available to service machinery overseas
