HOT MELT BUTYL EXTRUDER BUTYL MACHINE DOUBLE GLAZING GLASS MACHINE

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 3days

Brand: Lijiang

Product Description

working characteristics

Main feature

Touch-screen operation which makes the machine simple and practical

Auto-centering and auto clamping

The wheel material is Teflon brand ,non-stick coating, non-adhesive belt

Nuzzle height can be adjust, solve the gap between spacer and butyl

The coating speed is up to 47m/min,save butyl is up to 30％

Rectangle & arc frame , decorative aluminum fram can be coat

Auto-measure the width of spacer, auto-adjust the distance of nozzle

(double side standard is 7-8g, our machine can do 4g thickness is 1-1.5mm ,width 3mm)

The crossbeam height is easy to adjust,we can control the height of butyl

Glue output and height is same level.

Alarm device when use out of butyl

Pre-heating function,set up a regular time before .

Glue cylinder stands upside,easy to change glue

Pressure valve German HAWE brand with high pressure resistance, keep the butyl well proportioned

Pneumatic component -Taiwan Airtac

Relay Japan OMROM

Japan quick-opening valve make sure the both sides of nozzle open and close at the same time

Germany HAWEI brand pressure can up to 25MPa,The pressure is stable that can make the glue was coating evenly

The front roller and the back roller are used for rectangular frame, the Arc roller is used for circular frame.

Electrical components are used famous brand

Pneumatic and Hydralic supercharging pump -German Maximator brand

control the pressure of outlet oil strongly.

Butyl extruder parameters

Name	Brand	Original
PLC	KINCO	China
Valve	HAWE	German
Low voltage electrical apparatus	SIEMENS	German
Hydraulic and pneumatic supercharging system	MAXIMATOR	German
Frequency converter	KINCO	China
Pneumatic components(cylinder/valve)	ARTAC	Taiwan
Quick exhaust valve/Vacuum generator	SMC	Japan SMC
Travel light	OMRON	Japan
Optical fiber	OMRON	Japan
