Primary Welding Molding Thyristor Diode Module Big Power Inverse Parallel
Price:
To be discussed later
MOQ:
1 set
Delivery Time:
10-15 work days
Brand:
Noker
Product Description
Primary Welding Molding Big Power Inverse Parallel Low On State Voltage Drop Low Voltage Thyristor Module
Features
1. Unique structural design, primary welding molding, avoid secondary sintering
2. Vacuum sintered structure with porosity less than 3%
3. GPP central gate chip ensures high reliability of products
4. High Thermal conductivity DBC Insulation layer
5. Chip welding without flux contamination
6. Small volume light weight
| Type |
IT (AV) TC=85°C(A) |
VDRM VRRM(V) |
IDRM IRRM(mA) |
VTM (V) |
@ITM (A) |
IGT (mA) |
VGT (V) |
di/dt (A/us) |
dv/dt (V/us) |
ITSM (kA) |
I2t (kA2S) |
Rjc (°C/W) |
Viso(V) | Outline |
| MT*25 | 25 | 600-1800 | 8 | 1.60 | 75 | 100 | 1.80 | 50 | 800 | 0.55 | 1.50 | 0.95 | 2500 | M1 M2 M3 |
| MT*40 | 40 | 600-1800 | 8 | 1.60 | 120 | 100 | 1.80 | 50 | 800 | 0.70 | 2.50 | 0.95 | 2500 | |
| MT*55 | 55 | 600-1800 | 8 | 1.60 | 150 | 100 | 1.80 | 50 | 800 | 1.00 | 5.00 | 0.65 | 2500 | |
| MT*70 | 70 | 600-1800 | 8 | 1.60 | 210 | 100 | 1.80 | 50 | 800 | 1.25 | 7.20 | 0.53 | 2500 | |
| MT*90 | 90 | 600-1800 | 10 | 1.60 | 270 | 100 | 1.80 | 100 | 800 | 1.60 | 12.8 | 0.41 | 2500 | |
| MT*90 | 90 | 1900-2400 | 15 | 1.60 | 270 | 100 | 1.80 | 100 | 800 | 1.60 | 12.8 | 0.41 | 3000 | |
| MT*110 | 110 | 600-1800 | 15 | 1.60 | 330 | 100 | 2.00 | 100 | 800 | 2.10 | 24.0 | 0.28 | 2500 | |
| MT*110 | 110 | 1900-2400 | 15 | 2.00 | 330 | 100 | 2.00 | 100 | 800 | 2.10 | 24.0 | 0.25 | 3000 | |
| MT*135 | 135 | 600-1800 | 20 | 1.60 | 410 | 120 | 2.00 | 100 | 800 | 3.70 | 72.2 | 0.20 | 2500 | M5 M6 M7 M8 M9 |
| MT*135 | 135 | 1900-3000 | 20 | 2.00 | 410 | 120 | 2.00 | 100 | 800 | 3.70 | 72.2 | 0.20 | 3600 | M9 |
| MT*160 | 160 | 600-1800 | 25 | 1.55 | 480 | 120 | 2.00 | 100 | 1000 | 5.20 | 145 | 0.17 | 2500 | M5 M6 M7 M8 M9 |
| MT*160 | 160 | 1900-3000 | 25 | 2.00 | 480 | 120 | 2.00 | 100 | 1000 | 5.20 | 145 | 0.17 | 3600 | M9 |
| MT*182 | 182 | 600-1800 | 25 | 1.55 | 550 | 120 | 2.00 | 100 | 1000 | 5.80 | 210 | 0.15 | 2500 | M5 M6 M7 M8 M9 |
| MT*182 | 182 | 1900-3000 | 25 | 2.00 | 550 | 120 | 2.00 | 100 | 1000 | 5.80 | 210 | 0.15 | 3600 | M9 |
| MT*200 | 200 | 600-1800 | 30 | 1.55 | 600 | 150 | 2.50 | 100 | 1000 | 6.50 | 259 | 0.14 | 2500 | M10 MS10 M11 |
| MT*200 | 200 | 1900-2600 | 35 | 1.80 | 600 | 150 | 2.50 | 100 | 1000 | 6.50 | 259 | 0.14 | 3200 | |
| MT*200 | 200 | 2800-3600 | 40 | 2.30 | 600 | 150 | 2.50 | 100 | 1000 | 7.10 | 259 | 0.14 | 4500 |
