High Brightness Free Standing Digital Signage Outdoor 43 Inch 49 Inch 55 Inch
High Brightness Free Standing Digital Signage Outdoor 43 Inch 49 Inch 55 Inch
1. Outdoor application
2. Sunshine readable, high brightness 2000 nits, auto dimming.
3. Waterproof
4. Anti- thief, Anti dust.
5. Application areas can be public bus station, out of shopping mall, store, etc.
6. Certication: IP65 level
7. Built-in air conditioner and fans optional.
| Specifications | |||||||||
| Panel size | 42" | ||||||||
| Display area(mm)/mode | 930(W)*523(H) 16:9 | ||||||||
| Maximum resolution | 1920*1080 | ||||||||
| Display color | 16.7M | ||||||||
| Pixel Pitch(mm) | 0.4845(H)*0.4845(V) | ||||||||
| Brightness (nits) | 2000cd/m2 | ||||||||
| Contrast | 4000:1 | ||||||||
| Visual angle | 178°/178° | ||||||||
| Response time | 5ms | ||||||||
| Life(hrs) | >60,000(hrs) | ||||||||
| Input and output | |||||||||
| LAN | RJ45 (for Network version) | ||||||||
| WIFI Module | 1 (for Network version) | ||||||||
| USB | 1 | ||||||||
| SD | 1 | ||||||||
| Speaker | 2*10W(9Ω) | ||||||||
| Video | |||||||||
| Color system | PAL/NTSC/SECAM | ||||||||
| Remote controller | IR Remote Controller | ||||||||
| OSD display( screen menu display) | |||||||||
| Menu language | Chinese/English | ||||||||
| Power | |||||||||
| Power supply | AC100~240V 50 /60 HZ | ||||||||
| Maximum power consumption | <=220W | ||||||||
| Standby power consumption | <5W | ||||||||
| Temperature | |||||||||
| Working temperature | 0℃~50℃ | ||||||||
| Storage temperature | -20℃~60℃ | ||||||||
| Working humidity | 85% | ||||||||
| Storage humidity | 85% | ||||||||
| Appearance | |||||||||
| Color/appearance | White,black,customized | ||||||||
| Case | Metal case SPCC | ||||||||
| Installation | Floor-standing | ||||||||
CPU: Allwinner A83T Cortex-A7 Eight-Core CPU 2GHz/RK3288
GPU: PowerVR SGX544
O/S: Android 4.4.4
RAM: 2GB
NAND FLASH: 8GB FLASH/EMMC
Networking: RJ45
Built-in Wireless 802.11b/g/n,WAPI(Ralink 8188)
USB Wireless Dongle
Interface: USB*2,SD*1,VGA*1,RJ45*1,Audio out*1,SIM port*1
Ports: USB*2,SD*1,VGA*1,RJ45*1,Audio out*1,SIM port*1
OSD Language: Chinese, English, Spanish, Russian, German, French, Arabic, etc.
Support split screen: Any split screen display, multiple window video player, can achieve different window showing different content
Processor: Intel Core i3-3217U @ 1.80GHz /I5 /I7
GPU: Intel HD4000 Graphics
Chipset: Intel Chipset HM65
Memory: DDR3 4GB ,Support up to 8GB
Ethernet: Realtek GBE RJ45,8111E
Audio: Realtek HD Audio,Support Line-in,Line-out,Mic-in,Spdif,Speaker
Display: VGA1,LVDS.
Storage: 128G SSD
Touch technology: capacitive touch
Touch model: 10 touch points
Induction object: Finger, pen, any opaque objects
Size of induction: Greater than or equal to 5 mm in diameter
Resolution: 8192*8192
Response time: First point 25ms consecutive points 8ms
Cursor speed: ≥200dots/second
Glass Thickness: 4mm Normal or Anti-glare tempered glass
Application
1. Public Places: Subway, Airport, Bookshop, Exhibition hall, Gymnasium, Museum, Conference
center, Talent market, Lottery center, etc.
2. Entertainment Places: Movie theatre, Fitness center, Vacational village, KTV bar, Internet bar,
Beauty salon, Golf course, etc.
3. Financial Institution: Bank, Security/ Fund/ Insurance company, etc.
4. Business Organizations: Supermarket, Shopping malls, Exclusive shop, chain store, 4S shop,
Hotel, Restaurant, travel agency, Chemist's shop, etc.
5. Public Service: Hospital, School, Telecom, Post office, etc.
6. Real Estate&Property: Apartment, Villa, Office building, Commercial office buildings, Model
houses, Sales offices, the entrance of elevator, etc
