Super Narrow Bezel Samsung Digital Signage Video Wall Displaysl 5x5 250W 450 Nits
Super Narrow Bezel Samsung Digital Signage Video Wall Displaysl 5x5 250W 450 Nits
Key Features:
Panel: A+ DID unit
Bezel seam: 3.5mm,
Brightness:450nits
Backlight: WLED
Color: 16.7 (8bit)
178° wide view angle.
Response time: ≤ 5ms.
Easy-going modular design
7*24 uninterrupted working.
Supportive to IR and RS232
| Model No. | TPK-DID4901 | |
|
LCD |
Size | 49inch LG anel |
| Resolution | 1920(H)x1080(V) | |
| Pixel pitch | 0.53025(H)x0.53025(V) | |
| Backlight | LED | |
| Brightness(typical) | 500cd/m² | |
| Contrast | 1300 : 1 | |
| Viewing angel (H/V) | 178° / 178° | |
| Color depth | 16.7M | |
| Response time | <8ms | |
| Display area | 1073.8(H)×604(V) | |
| Bezel | 3.5mm | |
| Interface | CVBS In / Out (BNC ) | 1/1 |
| VGA In / Out | 1/0 | |
| DVI In / Out | 1/0 | |
| HDMI In/Out | 1/0 | |
| DEBUG(USB) | 1/0 | |
| Control | IR remote control | Yes |
| RS-232 In/Out | 1/2 | |
| Physical parameter | Dimension | 1057.58x605.8x113.7mm |
| Frame color | Black | |
| Frame material | Metal | |
| Net weight | 13.5Kg | |
| Power | Power consumption | 198W |
| Standby | <1W | |
| Power supply | AC 100V-240V, 50/60Hz,Universal,±10% | |
| Environment | Operating humidity | 20-90% RH(no condensation) |
| Storage humidity | 10-90% RH (no condensation) | |
| Operating temperature | 0 ~ 50° C / 32 ~ 122° F | |
| Storage temperature | -20 ~ 60° C / -4 ~ 140° F | |
| Accessory | Standard accessories | Power cable(1.8m, User manual, Warranty card, Quality certificate |
| Optional accessories | Wall mounted brackets, floor stand brackets, cabinet | |
| *design and specifications are subject to changes without prior notice | ||
Advantages of LCD Video Wall
♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
♦ Low power consumption and low heat radiation
♦ Long service life lowers the cost of usage and maintenance
♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
♦ Economical and practical: High performance and high quality make it cost less.
