43 / 55 Inch Waterproof Advertising Screen 2500nits Outdoor Digital Signage Kiosk
43 55 inch waterproof advertising screen outdoor digital signage kiosk
TOP ADKIOSK Outdoor LCD Kiosk
Outdoor Waterproof IP65 Interactive Stand Alone kiosk
1. Waterproof: sealed enclosures, high quality powder coating.
2, Dusty proof-with dust gauze.
3, lightning protection.
4. With tempered glass of 6mm, anti glare/refelection, ultraviolet-proof. LAMINATED GLASS: 3MM AR+3MM AG, UV proof.
5. Built-in cooling fan system.
6, Air conditioner Optional for cooling and heating
Specification Of Outdoor LCD Digital Signage
| Display | Backlight | LED |
| Display Area (mm) | 1073.78(H)*604(V)mm | |
| Active Size | 49"(43", 49", 55",65" available) | |
| Display Ratio | 16:09 | |
| Resolution (pixel) | 1920*1080 | |
| Display colors | 16.7M (8-bit) | |
| Brightness | 350cd/m2 | |
| Contrast | 1500:01:00 | |
| Response Time | 5ms | |
| Video Format | PAL/NTSC/SECAM | |
| Connectivity | Network | Ethernet,WiFi,3G/4G(optional) |
| Interface | 2*USB, RJ45*1 | |
| Touch | Touch Surface | Anti-Reflection Tempered Mirror Glass |
| Touch Sensor | Capacitive | |
| Touch Points | 10 Points | |
| CPU | Android Pro | Android Quad core CPU, 2G RAM, 8G storage |
| Windows Lite | Intel® Celeron 1037U Dual core CPU 4G RAM,128G SSD | |
| Windows Pro | Intel® Ivy Bridge i3 Dual core CPU 4G RAM,128G SSD | |
| OS | Android | Android 4.2 version above |
| Windows | Windows 7, 8.1, 10 | |
| Software | HD-DS | Support both Android and Windows OS; |
| Digital signage software, support both touch or non-touch program; | ||
| Support central manage multiple kiosks etc.. | ||
| Power | Consumption | 150W |
| Supply | AC100-240V,50-60Hz | |
| Mechanic | Speaker | 10W*2 Stereo audio |
| Product Dimension(mm) | 1800*728*66 | |
| Package Dimension (mm) | 1885*820*175 | |
| Weight(KG) | 60 |
Application
1. Public Places: Subway, Airport, Bookshop, Exhibition hall, Gymnasium, Museum, Conference
center, Talent market, Lottery center, etc.
2. Entertainment Places: Movie theatre, Fitness center, Vacational village, KTV bar, Internet bar,
Beauty salon, Golf course, etc.
3. Financial Institution: Bank, Security/ Fund/ Insurance company, etc.
4. Business Organizations: Supermarket, Shopping malls, Exclusive shop, chain store, 4S shop,
Hotel, Restaurant, travel agency, Chemist's shop, etc.
5. Public Service: Hospital, School, Telecom, Post office, etc.
6. Real Estate&Property: Apartment, Villa, Office building, Commercial office buildings, Model
houses, Sales offices, the entrance of elevator, etc
Extreme Temperature
1. Intelligent air conditioner cooling system integrated cooling and heating;
2. Unique patented intelligent temperature control technology;
3. Work stably and efficiently in wide temperature range from -40°C to +55°C;
4. housing enclosure made of non-oxidizing material zinc coted steel.
Vandal Proof
1. Strong steel housing protects inner system from vandalism;
2. AR bonding TM protection 6mm laminated / tempered glass prevents direct LCD panel assault;
3. Easy to remove and reinstall housing protective makes provide simple but effective protection of core enclosure;
4. Enclosed parts are not reachable to passerby.
