BRPV3-1500-12.5 DC SPD 1500V 12.5kA PV Surge Arrester T1 T2 Surge Protection
A DC surge protective device is an essential component for safeguarding sensitive electronic equipment from voltage spikes and surges caused by lightning strikes and other electrical disturbances. The BRITEC DC Surge Protection Device provides advanced protection against transient overvoltage events with reliable performance and robust construction.
- High degree of protection with IP20 rating
- Clear visual indicators: Green (operational) / Red (fault)
- Durable thermoplastic UL94-V0 enclosure material
- Rapid response time of ≤25 nanoseconds
- Voltage protection level: 5.2kV
- Wide operating temperature range: -40℃ to +85℃
- Humidity range: ≤95%RH
- Plug-in modular format for easy installation
| Parameter | Specification |
|---|---|
| Operating State | Green / Red |
| Response Time | ≤25ns |
| Enclosure Material | Thermoplastic UL94-V0 |
| Voltage Protection Level | 5.2kV |
| Degree of Protection | IP20 |
| Cross-section Area (Min.) | 4mm² |
| Cross-section Area (Max.) | 35mm² |
| Format | Plug-in Modular |
The BRPV3-1500-12.5 DC Surge Protection Device is ideal for protecting electrical equipment in various applications including industrial facilities, commercial buildings, data centers, telecommunications equipment, and solar power systems where protection against voltage fluctuations is crucial.
Brand Name: BRITEC
Model Number: BRPV3-1500-12.5
Place of Origin: China
Certification: TUV/CB/CE/ROHS/ISO9001
Minimum Order Quantity: 2PCS
Packaging Details: Carton
Delivery Time: 15 days after receipt of deposit
Payment Terms: TT
Supply Ability: 1,000,000 per month
Our DC Surge Protection Device comes with comprehensive technical support and services to ensure optimal performance and protection of your electrical systems. Our expert team provides assistance with installation, troubleshooting, maintenance, and offers training programs on best practices for equipment protection.
