BR-POE-M 48V POE Surge Protector NET 6 POE surge protectors
Price:
Negotiable
MOQ:
50 PCS
Delivery Time:
15 days after receipt of deposit
Brand:
BRITEC
Product Description
BR-POE-M 48V RJ45 Surge Protection Ethernet Surge Protector
The "Net Defender" permits the use of Power over Ethernet (PoE) surge protector with nominal currents of up to 1 A. It can be snapped directly onto the hat rail and uses it to create the necessary equipotential bonding. Alternatively, terminal protection using a separately connectable.
Key Features
- POE Ethernet surge protector for comprehensive network protection
- Ideal for wireless APs, network cameras, switches and other communications equipment
- Integrated power supply + signal POE surge protection design
- High-quality components for excellent performance
- Low residual voltage with efficient surge protection
- Fast response time with stable, reliable operation
- Compact size for convenient application and maintenance-free operation
Technical Specifications
| Specification | BR-POE-M |
|---|---|
| Test standards | IEC 61643-21 |
| SPD class | TYPE2 P1 |
| Nominal voltage | 48V |
| Max. continuous operating d.c. voltage | 48V |
| Max. continuous operating a.c. voltage | 34V |
| Max. continuous operating d.c. voltage pair-pair(PoE) | 57V |
| Nominal current | 1A |
| D1 Lightning impulse current (10/350 μs) per line | 0.5kA |
| C2 Nominal discharge current (8/20μs) line-line | 150A |
| C2 Nominal discharge current (8/20μs) line-PG | 2.5kA |
| C2 Total nominal discharge current (8/20μs) line-PG | 10kA |
| C2 Nominal discharge current (8/20μs) pair-pair(PoE) | 150A |
| Voltage protection level pair-pair for In C2 | ≤180V |
| Voltage protection level line-PG for In C2 | ≤500V |
| Voltage protection level line-line for In C2(POE) | ≤600V |
| Insertion loss at 250 MHz | ≤3dB |
| Capacitance line-line | ≤30pF |
| Capacitance line-PG | ≤25pF |
| Operating temperature range | -40℃ to +80℃ |
| For mounting on | 35mm DIN rails acc. to EN 60715 |
| Connection (input/output) | RJ45 socket/RJ45 socket |
| Pinning | 1/2, 3/6, 4/5, 7/8 |
| Earthing via | 35mm DIN rails acc. to EN 60715 |
| Enclosure material | Polyamide PA 6.6 |
| Degree of protection (plugged-in) | IP10 |
| Order Code | D9160 |
Additional Parameters
| Parameter | Value |
|---|---|
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Nominal Voltage | 48V |
| Material | Aluminum Alloy |
| Warranty | 3 Years |
| IP Code | IP20 |
| Adapt Transmission Rate | 1000Mbps |
| Humidity Range | 0-95% RH |
Applications
BRITEC Ethernet Surge Protection Devices, model number BR-POE-M, provide reliable surge protection for Ethernet networks. Certified by TUV, CB, CE, ROHS, and ISO9001, these protectors are suitable for various applications requiring RJ45 surge protection with a 1000Mbps transmission rate.
- Industrial Environments: Protects Ethernet networks in industrial settings against electrical surges
- Commercial Buildings: Safeguards Ethernet connections in offices and retail spaces
- Outdoor Installations: Durable design withstands outdoor conditions (-40°C to +85°C)
- Data Centers: Protects critical network infrastructure in data-intensive operations
Ordering Information
| Detail | Information |
|---|---|
| Brand Name | BRITEC |
| Model Number | BR-POE-M |
| Place of Origin | China |
| Certification | TUV/CB/CE/ROHS/ISO9001 |
| Minimum Order Quantity | 10 PCS |
| Packaging Details | Carton |
| Delivery Time | 15 days after receipt of deposit |
| Payment Terms | TT |
| Supply Ability | 1,000,000 units per month |
Frequently Asked Questions
Q: What is the brand name of this Ethernet Surge Protection Device?
A: The brand name is BRITEC.
Q: What is the model number of this Ethernet Surge Protection Device?
A: The model number is BR-POE-M.
Q: Where is this Ethernet Surge Protection Device manufactured?
A: It is manufactured in China.
Q: What certifications does this Ethernet Surge Protection Device have?
A: It is certified by TUV, CB, CE, ROHS, and ISO9001.
Q: What is the minimum order quantity for this Ethernet Surge Protection Device?
A: The minimum order quantity is 10 PCS.
