BRITEC AC 12.5kA BR-12.5M 275V T1+T2 Surge Arrester Class B+C
Price:
USD 40-80 Piece/Pieces
MOQ:
100 Piece/Pieces
Delivery Time:
Shipped in 15 days after payment
Brand:
BRITEC
Product Description
BRITEC Manufacturer 12.5kA Class I + II Surge Protection Device AC 3 Pole SPD 3p
Class I + II Surge Protection Device Feature:
• It is designed according to IEC61643-1, GB18802.1.
• Maximum current of endure the lightning stroke 50KA.
• Time of response<25ns.
• It adopts 35mm standard rail.
• Pluggable module, easy for installation and maintenance.
• High discharge capacity, quick response.
• There is a failure release mounted in the module of surge protection device.
• When the SPD fails in breakdown for over-hart and over-current, the failure release will help electric equipment separate from the power supply system and give the indication signal, green means normal, red means abnormal.
Class I + II Surge Protection Device Product Details:
| BR-12.5M-275 3P | |
| SPD classification according to EN 61643-11 | Type 1 + Type 2 |
| SPD classification according to IEC 61643-11 | Class I + Class II |
| Rated Voltage(max. continous voltage) Uc | 275V |
| Lightning impluse current (10/350us) Iimp | 12.5kA |
| Nominal discharge current (8/20us) In | 20kA |
| Max. discharge current (8/20us) Imax | 50kA |
| Voltage protection level Up | ≤1.3kV |
| Max.Back up fuse | 160A |
| Response time tA | ≤25ns |
| Power supply system | 3 phases TN-C system |
| Technology | MOV |
| Format | Plug-in modular |
| Operating Environment Tu | -40 degree to + 80 degree |
| Operating state / fault indication | green / red |
| Cross-section area | 4mm2~35mm² solid |
| Installation | 35mm Din rail |
| Protection degree | IP20 |
| Material of outer covering | Thermal plastic UL94-V0 |
| OEM | Yes |
| Remote Signalling | Optional |
| Dimension | 3mods |
Dimension:
Class I + II Surge Protection Device Application:
• BR-12.5M 3P AC SPD is suitably used in the TN-C power supply system of AC 50/60Hz.
• Applied in modular SPD Class I + II (Class B + C).
• Protecting low voltage equipment from surge damages.
Class I + II Surge Protection Device Product introduction:
In order to meet with user demand, we developed new generation BR-12.5M series protector with built-in circuit breaking device, to limit surge current, overvoltage, over-current occurred in the power system duo to some reasons, working in the system of AC 50Hz, rated voltage 320V and below to prevent surge voltage from damaging electric equipment.
Shipping:
Factory picture:
About us:
Wenzhou Britec Electric Co., Ltd. has been committed to low voltage surge arrester products’ designing, R&D, manufacturing and marketing for 17 years. Britec factory locates in Wenzhou, Zhejiang, China. We own well-trained workers, rich experience production and R&D engineers. With qualified raw materials and components, all products are manufactured to defined specifications, applying ISO9001 quality control system and in compliance with relevant international approvals, such as CE, CB, TUV. Our team can develop and test new products to meet variable markets’ tailored demands. Britec branded and OEM/ODM products are widely served for residential, commercial and industrial applications in 50+ countries and districts.
Certification:
FAQ:
Q1: What's your warranty?
A1: The warranty is 2 years.
A1: The warranty is 2 years.
Q2: How about inspection?
A2: Our Test standard: IEC 61643-1 / EN 61643-11/ UL1449 ed.4/GB 18802.1, and the Vibration and Shock according standard : DIN EN 60068-2-6 and DIN EN 60068-2-27, as well as the Degree of protection according to IEC EN60529: IP 20.
A2: Our Test standard: IEC 61643-1 / EN 61643-11/ UL1449 ed.4/GB 18802.1, and the Vibration and Shock according standard : DIN EN 60068-2-6 and DIN EN 60068-2-27, as well as the Degree of protection according to IEC EN60529: IP 20.
Q3: What's the standard of package?
A3: Inner box and out carton are made as per international standard and we can make special design according to customer's need.
Q4: Could you do OEM for us?
A4: Sure,OEM is acceptable, and please supply with the brand letter of Authorization.
A4: Sure,OEM is acceptable, and please supply with the brand letter of Authorization.
Q5: What is the payment terms?
A5: T.T, PayPal is acceptable.
A5: T.T, PayPal is acceptable.
