Food Grade Refrigerated Compressed Air Dryer Stainless Steel Alkali Anti Corrosion

Super Cooling 150HP 25m3/min Cheaper Industrial refrigerated air dryer

Features of High-temp Refrigerated Air Dryer:

Capacity: 25m3/min

 Working Pressure: ≤13bar
Max.inlet temp: 82°C Max Ambient Temp:50°C
Min.Ambient Temp: 5°C Refrigerant: R22, R407C,R134A,R410A
Cooling type: Air-cooled&Water-cooled Dew Point: 2°C ~8°C

Description of 150HP 25m3/min Cheaper Industrial refrigerated air dryer:

1. Shanghai rotorcomp compressor dryer Using filtered liquid separator American HANKISON filter, Japanese Panasonic & Korean LG Refrigeration compressor to keep durability and stability. Gas-liquid separation effect completely to avoid secondary evaporation of moisture, cold and dry to ensure that the important role of the drying effect, it is more efficient than the cyclone separation, separation efficiency 99.99%.

2. Galvanized copper piping systems using internal working pressure 0.3-4.5MPa arbitrary choice.

3. Made of stainless steel tubing for pharmaceutical, food industry, acid and alkali corrosion.

Is the dehumidification of the dryer must be caused by insufficient dew point?

Compressed air dryness refers to the amount of water vapor mixed in dry compressed air. When the water vapor content is low, the air is dry, and vice versa.

Compressed air dryness is measured by the "pressure dew point", the "pressure dew point" is low, and the compressed air is dry. Sometimes a small amount of liquid water is mixed in the compressed air discharged from the dryer, but this is not necessarily caused by insufficient dew point of the compressed air.

The presence of liquid water droplets in the exhaust gas may be caused by water accumulation in the machine, poor drainage or incomplete separation, especially the damage caused by the blockage of the automatic drainer. The venting water of the dryer is less than the dew point, which can bring worse adverse effects to the downstream gas equipment. The cause should be eliminated.
