Coal Mining Rock Drill Steel Rod H22 Hex Tapered Hollow Drill Rod Color Custom
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
Within 7-12 days
Brand:
ShiTan
Product Description
Coal Mining Rock Drill Steel Rod H22 Hex Tapered Hollow Drill Rod Color Custom
Product Attributes
| Attribute | Value |
|---|---|
| Parts Name | Integral drill rod |
| Material | Carbon Steel |
| Application | Coal Mining |
| Processing Type | Forging |
| Machine Type | Drilling Tool |
| Color | Custom |
Product Introduction
Tapered drill rod is a further development of the integral drill rods. It usually has a forged collar to maintain the proper shank striking face position in the rock drill. Tapered drill rods effective lengths are measured from the collar to the bit end, which are usually from 0.6 meters to 3.6 meters.
Product Specification
| Rod dia(mm) | Rod Length(mm) | Thickness (mm) | Connect Thread | Trigger Slot |
|---|---|---|---|---|
| 3 (76mm) | 1000-6000 | 5 | API2 3/8"REG | 57/64.5 |
| 3 (76mm) | 1000-9000 | 8 | API2 3/8"REG | 57/64.5 |
| 3 1/2 (89mm) | 1000-6000 | 6 | API2 3/8"REG | 70/64 |
| 3 1/2 (89mm) | 1000-9600 | 8 | API2 3/8"REG | 70/64 |
| 4 (102mm) | 1000-9000 | 10 | API2 3/7"REG | 76/89 |
| 4 1/2 (114mm) | 1500-7620 | 6 | API3 1/2"REG | 89/95 |
| 4 1/2 (114mm) | 1500-9140 | 8 | API3 1/2"REG | 89/95 |
| 4 1/2 (114mm) | 1500-9140 | 10 | API3 1/2"REG | 89/95 |
| 4 1/2 (114mm) | 1500-9140 | 18 | API3 1/2"REG | 89/95 |
Sanrock Drill Pipe Features
- Pipe body: Cold draw seamless pipe for accurate size and good centralizer
- Material: Same grade
- Thread connector: Heat and Nitrogen treatment for durability and easier loading/unloading
- Welding: Friction welding
Standard DTH Drill Pipe Specifications
Diameter: 76mm, 89mm, 102mm, 114mm, 127mm, 140mm
Length: 1000mm, 1500mm, 2000mm, 3000mm, 5000mm, 6000mm
Thread: 2 3/8" API REG, 2 7/8" API REG, 3 1/2" API REG, 4 1/2" API REG, 2 3/8 API IF, 3 1/2 API IF
Four Functions of Lubrication for Water Well Drilling Rig
- Reducing friction: The main function of oil lubrication, preventing direct metal contact to reduce friction resistance and wear loss
- Cooling and heat dissipation: Disperses heat from high-speed rotating parts to prevent temperature buildup and part burning
- Rust prevention: Grease application prolongs service life of metal parts exposed to rain and prevents rust
- Sealing blockage: Oil-immersed wool felt in sealing packing and bearing end covers effectively seals and prevents dust
