Mud Pump Integrated Geological Drilling Rig Machine for SPT Investigation
Price:
Negotiation
MOQ:
1 set
Delivery Time:
7-10 days
Brand:
JINZHOU SHITAN
Product Description
Mud Pump Integrated Geological Drilling Rig Machine for SPT Investigation
Product Description:
1. With mud pump attached on the rig
2. Large torque, multiple drilling speeds in an appropriate range
3. Capable to drill inclined holes at different angle.
4. High efficiency drilling with hydraulic feeding structure
5. Multiple usages, geotechnical investigation for engineering constructions, mineral exploration, small size pile hole, water well boring
Product Parameter:
| Drilling depth | 200m |
| Max open hole caliber | 300mm |
| End hole caliber | 75mm |
| Drill rod caliber | 60mm |
| Drilling angle | 90°~75° |
| Drill weight (without power) | 975kg |
| Triangle convert belt | B950 x 4 B1700 x 3 |
| The main machine moving distance | 300mm |
| Power | Diesel engine 22KW /Electric motor 15kw |
| Spindle | |
| spindle speed | 64, 128, 287, 557r/min |
| Spindle stroke | 450mm |
| Hoist | |
| Max.lifting capacity | 2400kg |
| Single line lifting speed | 0.41, 0.82, 1.64m/s |
| Wire rope caliber | 13mm |
| Wire rope length | 35m |
| Reel diameter | 140mm |
| Hug floodgate caliber | 260mm |
| Hug floodgate belt width | 70mm |
| Mud pump | |
| Type | Horizontal single-urn twin-action |
| Displacement | Diesel engine 170L/min Electric motor 150L/min |
| Maximum pressure | 3Mpa |
| Work pressure | 1.5Mpa |
| Inlet pipe caliber | 40mm |
| Outlet pipe caliber | 30mm |
| Triangle convert belt | B1728mm |
| Hydraulic oil pump | |
| Type | CBT-F-314 |
| Triangle convert belt | B1100 X 1 |
